Trine 2012 Series - Fail-Secure, Adjustable Light Commercial Electric Strike 4-7/8" x 1-1/4" Steel Face Plate

Trine 2012 Series - Fail-Secure, Adjustable Light Commercial Electric Strike 4-7/8" x 1-1/4" Steel Face Plate

(No reviews yet) Write a Review

Model: 2012C-16-24AC/DC
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$157.00
$122.22
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Trines Adjustable 2000 Series Electric Strikes

Trine 2012
For use in new or replacement, aluminum or hollow, metal jamb installations with locksets having up to 5/8” throw, based on 1/8” door gap.

Steel Face Plate 4-7/8” x 1-1/4” -- Auxiliary Ramp 3-3/8” -- Mortise Backset 1-9/16” -- Cavity Depth 9/16” -- Cavity Width 5/8” -- Cavity Height 1-11/16

Available Finishes: 2012 (Brass Powder Coated) -- 2012C (Satin Chrome or - BHMA652) -- 2012DB (Dark Bronze Powder Coated)
Options: RS (Fail Safe) -- on DC only -- add “RS” to model #

2000 Series Features:

  • Allows adjustment for wider latch bolts & poorly aligned doors & locksets.
  • 1/8” Horizontal Latch Adjustment.
  • Releases Under Slight Door Pre-Load.
  • 500,000 Life Cycles -- Holding Force - 900 lbs.
  • Solid Cast Latch - Chrome Plated.
  • Non Handed Operation.
  • Screw Terminals - Quick Connection.

2000 Series Electrical Characteristics:

Voltage Current/Amps Ohms (Ω) Sound Duty
6-14VAC 0.44 - 1.10 8.5 Buzz Intermittent
6-14VDC 0.70 - 1.60 8.5 Silent Continuous
16-24VAC 0.22 - 0.33 50.0 Buzz Intermittent
16-24VDC 0.32 - 0.47 50.0 Silent Continuous
12VDC 0.20 - 0.33 60.0 Silent Continuous
24VDC 0.11 - 0.47 120.0 Silent Continuous

Downloadable content:

2012 Dimensions (PDF)

Manufacturer Resources

Product Specs

Series:
2012
Product Group:
Electronic Access Controls
Product Subgroup:
Electric Strikes
Product Type:
Electric Strikes
Subcategory:
Electric Strikes
Commercial/Residential:
Commercial
Electronic:
Yes
Outdoor Rated:
No
Lock Type:
Mortise or Cylindrical
Fail-safe / Fail-secure:
Fail-Secure
Face Plate:
4-7/8"
Fire Rating:
No
Product Category:
Electronic Access Controls
Department:
Door Hardware

Trine 2012C-16-24AC/DC – Frequently Asked Questions

1) What jamb does the Trine 2012 strike mount into, and what is the cutout?
Aluminum or hollow metal jambs, new construction or replacement. The steel face plate is 4-7/8 x 1-1/4 inches, mortise backset 1-9/16 inches, and the cavity behind it is 9/16 deep by 5/8 wide by 1-11/16 high, with a 3-3/8 inch auxiliary ramp. Wood jambs are not what this one is listed for.
2) What happens to the Trine 2012 strike when the power goes out?
It stays locked. The 2012 is fail-secure, so loss of power leaves the keeper held and the door secured from the outside; the lockset's own lever or knob still lets people out from the inside. If your access control scheme needs the door to release on power loss instead, the fail safe version is the RS variant, and RS is DC only. Field-selectable options in the same catalog include the Hager 2925 and 2928, both field reversible fail safe/secure.
3) What voltage do I order the Trine 2012 electric strike in, and will it run continuous duty?
Four voltage choices: 6-14VAC/DC, 16-24VAC/DC, 12VDC, and 24VDC. Run it on DC and it is silent and rated continuous duty, so you can hold it energized on an intercom or card system. On AC it buzzes and is intermittent duty only, meant for momentary release. Current draw is 0.20-0.33A at 12VDC (60 ohms) and 0.11-0.47A at 24VDC (120 ohms), which is what you size the supply and the run of wire against. Screw terminals, so no pigtail splicing in the jamb.
4) Which electric strikes look like a Trine 2012 substitute but will not work for a mortise or cylindrical lock latch?
A few strikes in the same family solve a different latch entirely. The SDC 30-4 Series is a rim mount strike for a 3/4 inch Pullman latchbolt, the Hager 2945 is a rim exit strike, and the HES Folger Adam 310-4-2 is a complete strike pac for surface vertical rods, all of which serve exit device hardware rather than a mortise or cylindrical lockset. The SDC 25 Series is cut for a 1/2 inch latchbolt, and the RCI 15BS is an economy fail-secure strike for a special offset latch entry. The Trine 2012 is made for mortise or cylindrical locks with up to 5/8 inch throw.
5) What is a fire-rated alternative to the Trine 2012 electric strike?
The Trine 2012 is not fire rated, so it should not go into a labeled opening. For fire-rated work with a comparable lock scope, the Von Duprin 6400 32D is a Grade 1 modular fail-secure electric strike for mortise or cylindrical locks with a 3-hour UL 10C rating, and the Hager 2930 is a fire-rated Grade 1 strike for cylindrical and mortise locks with 12/24VDC dual voltage. The Camden CX-ED1410 and CX-ED1420 are fire-rated Grade 1 ANSI universal strikes if you want one part to cover mixed openings.
6) What electric strike can I use on an exterior gate instead of the Trine 2012?
The Trine 2012 is not outdoor rated and is intended for aluminum or hollow metal jamb installations. For a gate or other exposed opening, the Camden CX-ED1959 Series is an outdoor rated electric gate strike.
7) What electric strike has the same 4-7/8 by 1-1/4 inch faceplate as the Trine 2012?
Several strikes share that ANSI faceplate footprint, so the jamb prep carries over. The Adams Rite 7100 has a flat 1-1/4 by 4-7/8 inch faceplate for aluminum jambs, the Adams Rite 7160 uses the same 1-1/4 by 4-7/8 inch faceplate for aluminum jambs, and the Adams Rite 7170 uses it for hollow metal and wood jambs. The Dortronics 3300 Series also uses a 4-7/8 by 1-1/4 inch strike plate for ANSI prep and adds a latch bolt sensing switch on 12/24VDC.
8) Which electric strike should I use instead of the Trine 2012 on a heavy traffic opening?
The Trine 2012 is built for light commercial duty. Where an entrance takes constant traffic and the spec calls for a graded body, the Alarm Controls AES-100 is a Grade 1 heavy duty electric strike, the Von Duprin 4211 32D is a Grade 1 heavy duty strike for cylindrical locks with 12/24VDC field-selectable voltage, and the Locknetics MDS100 US32D and MS100 US32D are heavy duty strikes in satin chrome. The Securitron MUNL mortise UnLatch is a Grade 1 fire-rated option for mortise locks.
9) Is there a fail-safe electric strike similar to the Trine 2012?
The Trine 2012 is a fail-secure strike, which keeps the door locked when power drops. If the opening needs fail-safe operation, or if you want the choice made in the field rather than at order time, the Hager 2925 has field reversible fail safe/fail secure operation with a 5/8 inch latch, the Hager 2928 offers the same field reversible fail safe/secure function, and the Hager 2945 is a fire-rated rim exit strike with field selectable fail safe/fail secure and a latchbolt monitor.
10) What other electric strikes work with a 5/8 inch latch throw like the Trine 2012?
The Trine 2012 accepts locksets with up to 5/8 inch throw based on a 1/8 inch door gap. Peers cut for the same throw include the SDC 15 Series, a value strike for a 5/8 inch latchbolt with 12/24 VDC operation, the SDC 45F Series, a fire-rated strike for a 5/8 inch latchbolt with a radius corner faceplate, the Adams Rite 7240, a fire-rated strike for cylindrical locksets with 5/8 inch latchbolt projection, and the Hager 2925 with a 5/8 inch latch. The HES Folger Adam 310-1(X) strike body covers 1/2, 5/8 or 3/4 inch throw latchbolts.
11) Do I have to order the Trine 2012 strike handed for a left or right hand door?
No handing to specify. The 2012 is non handed, so one part covers both swings, which matters if you are stocking spares across a building rather than ordering per opening.
12) Is the Trine 2012 strike tough enough for a busy entry door?
It is a light commercial strike rated for 500,000 cycles with 900 lbs holding force, and the latch is solid cast and chrome plated. That suits a tenant entry, an office suite door, or a storefront on moderate traffic. For a high-abuse opening or where a Grade 1 heavy duty spec is called out, look at the Alarm Controls AES-100 or the Von Duprin 4211, both Grade 1 heavy duty.
13) My door is out of alignment and the old strike keeps binding. Will the Trine 2012 solve that?
That is what the adjustment is for. The keeper moves 1/8 inch horizontally to pick up a latch that no longer lands square, which covers wider latch bolts and doors and locksets that have gone out of alignment. It also releases under slight door pre-load, so a door leaning on the keeper from wind or a closer still lets go when energized. It will not fix a gap larger than the 1/8 inch the 5/8 throw rating assumes.
14) What electric strike adds latch monitoring that the Trine 2012 does not have?
The Trine 2012 provides screw terminal connections for the release circuit only. If the access control system needs to know the door state, the Dortronics 3300 Series includes a latch bolt sensing switch and runs on 12/24VDC with a 4-7/8 by 1-1/4 inch strike plate for ANSI prep, the Hager 2945 is a fire-rated rim exit strike with a latchbolt monitor, and the Camden CX-ED1799L-8 is a Grade 1 dual monitor strike supplied with eight faceplates.
15) Is there an electric strike that avoids cutting the jamb the way the Trine 2012 requires?
The Trine 2012 is a mortised strike with a 1-9/16 inch mortise backset and a 9/16 inch cavity depth, so the jamb has to be prepped. The Locknetics NC450 US32D is a no cut electric strike, and the Camden CX-ED1689L-4 is a fire-rated universal low profile strike supplied with four faceplates, which gives more room to match an existing prep on a retrofit.
16) Which strike matches the Trine 2012 satin chrome finish for a facility standard?
The Trine 2012 comes in satin chrome (BHMA 652) along with brass powder coated and dark bronze powder coated. If other openings in the building take a different strike, the Locknetics CS450-32D, MDS100 US32D, MS100 US32D and NC450 US32D are all supplied in the 32D satin stainless family, as are the Von Duprin 4211 32D and the Von Duprin 6400 32D in satin stainless steel, so a mixed order still reads consistently across the doors.
17) What is the equivalent to the Trine 2012 for a pair of doors or a double door opening?
The Trine 2012 is a single non-handed strike for aluminum or hollow metal jambs. For a pair, the Rockwood electric strike for double doors uses a 3/4 keeper and is a Grade 1 fire-rated part in the 310-1 series.
18) Which mortise lock electric strike is comparable to the Trine 2012 for a 24VDC fail-secure circuit?
The Trine 2012 is offered in a 24VDC fail-secure build, and also in 12VDC, 6-14VAC/DC and 16-24VAC/DC. For the same 24VDC fail-secure duty on a mortise lock in a labeled opening, the Von Duprin 6210 is a heavy duty Grade 1 electric strike for mortise locks, 24 VDC fail-secure, UL 10C fire rated.
19) What finishes does the Trine 2012 strike come in and will it match my other jambs?
Three finishes across all four voltages: brass powder coated (model 2012), satin chrome (2012C, BHMA 652), and dark bronze powder coated (2012DB). Satin chrome is the one that blends with the 626/652 lever and closer hardware most commercial buildings already run; dark bronze matches anodized bronze aluminum storefront.
