WAC Lighting 66-ARCH Archetype LED Bollard Light, 277V, IP66 Rated
The WAC Lighting 66-ARCH Archetype LED Bollard Light delivers soft, even pathway illumination in a sleek linear design built for demanding outdoor environments. Cast from a special K-alloy aluminum and factory sealed to an IP66 rating, this 277V fixture is engineered to resist high-pressure water jets and outdoor elements while delivering up to 390 lumens at 90 CRI from a high-powered LED rated for 60,000 hours. Backed by UL and cUL 1598 listing, the Archetype Bollard Light is suited for wet-location landscape and hardscape installations.
Key Features
- Durable Construction: Cast from a special K-alloy aluminum engineered to withstand challenging outdoor environments over time, available in a bronze or black finish.
- 277V Input: Wired for 277V AC operation with smooth, continuous dimming to 10% using an ELV Dimmer.
- High-Powered LED: 10.5W total wattage delivering up to 390 lumens at 90 CRI with a 60,000-hour rated lifespan.
- IP66 Rated: Factory sealed and water tight for protection against high-pressure water jets and outdoor elements, suitable for wet locations.
- Finish Options: Available in a bronze or black finish for coordinated landscape lighting schemes.
- Mounting Accessory Included: Ships with a guardian spike mounting accessory and a 3ft lead wire with two gel-filled direct burial wire nuts; optional concrete pour kit sold separately (SKU# M66-CON-KIT).
Certifications & Compliance
- UL Listed
- cUL Listed
- UL & cUL 1598
- IP66 Rated for Wet Locations
Technical Specifications
- Bulb Base: LED Module - ACLED Module
- Bulb Shape: LED
- Bulbs Included: Yes
- Dimmable: ELV
- Energy Star: No
- Hardwired or Portable: Hardwired
- Number of Bulbs: 1
- Product Type: Bollard Lighting
- Safety Rating: UL;cUL;IP66
- Shade/Glass Description: Frosted Glass Lens
- Warranty: 5 Years Functional, 2 Years Finish
- Subcategory: Bollard Light
- Avg Rated Hours: 60000
- Beam Spread: Flood
- Voltage: 277
- Country of Origin: China
- Location Rating: Wet
- Total Wattage: 10.5
- Style: Modern
Typical Applications
- Landscape Pathway Lighting
- Outdoor Wet-Location Installations
- Garden and Walkway Illumination
- Commercial and Residential Hardscapes
Why WAC Lighting?
WAC Lighting builds the Archetype Bollard Light from corrosion-resistant K-alloy aluminum with an IP66 watertight seal and UL & cUL 1598 listing, delivering reliable, code-compliant performance for outdoor electrical installations. With a 5-year functional and 2-year finish warranty, this fixture is engineered for long-term landscape lighting reliability.
Manufacturer Resources
Specification Sheet
Product Specs
- Bulb Base:
- LED Module - ACLED Module
- Bulb Shape:
- LED
- Bulbs Included:
- Yes
- Collection:
- Archetype
- Dimmable:
- ELV
- Energy Star:
- No
- Hardwired or Portable:
- Hardwired
- Number of Bulbs:
- 1
- Product Type:
- Bollard Lighting
- Safety Rating:
- UL;cUL;IP66
- Shade/Glass Description:
- Frosted Glass Lens
- Subcategory:
- Bollard Light
- Avg Rated Hours:
- 60000
- Beam Spread Angle:
- Flood
- Product Voltage:
- 277
- Product Material:
- K-Alloy Aluminum
- Location Rating:
- Wet
- Total Wattage:
- 10.5
- Product Style:
- Modern
- Department:
- Electrical
WAC Lighting 6643-27BK – Frequently Asked Questions
1) Can the WAC Archetype 66-ARCH bollard run on a 120V landscape circuit?
No. The 66-ARCH Archetype bollard is wired for 277V AC only, so it belongs on a 277V branch circuit, typically the high leg of a commercial 277/480V system. It will not work on a 120V residential or 12V low-voltage landscape run. If your site is 120V, you need the 120V version of the Archetype bollard instead.
2) Is the WAC Archetype LED bollard approved for wet locations and direct contact with sprinklers?
Yes. The Archetype bollard carries a Wet location rating and is factory sealed to IP66, which covers high-pressure water jets, so irrigation spray, rain, and washdown are all within rating. It is UL and cUL Listed to UL/cUL 1598.
3) How does the 66-ARCH bollard mount, and do I need anything extra for a concrete walkway?
It ships with a guardian spike mounting accessory plus a 3 ft lead wire and two gel-filled direct burial wire nuts, so a soil or planting-bed install is complete out of the box. For concrete, the spike is no use; order the optional concrete pour kit M66-CON-KIT, which is sold separately.
4) What do I have to specify when ordering the WAC 66-ARCH Archetype bollard?
Two choices: color temperature and finish. Color temperature is 2700K or 3000K, and finish is black or bronze. All four combinations are built, so 2700K black, 2700K bronze, 3000K black and 3000K bronze are each orderable. For a run of pathway bollards on one site, keep both the Kelvin and the finish identical across the order so the walkway reads consistent.
5) What dimmer works with the WAC Archetype 277V bollard?
Use an ELV (electronic low voltage) dimmer. On that control the fixture dims smoothly and continuously down to 10 percent. A standard incandescent/TRIAC wall dimmer is not the right control for it, and the dimmer must itself be rated for 277V line voltage.
6) Is 390 lumens enough light for a commercial walkway, and how far apart should bollards go?
The Archetype bollard puts out up to 390 lumens from a 10.5W LED behind a frosted glass lens, with a flood beam spread. That is accent and wayfinding light, soft and even along a path, not area lighting. On a commercial walk it is normally specified as a continuous run of bollards rather than a few widely spaced units. For parking lots or open-area footcandle targets, a pole-mounted area fixture is the right tool.
7) Can the LED be replaced in the WAC Archetype bollard, or is the whole fixture throwaway?
The light source is an integral ACLED LED module, one per fixture, included and factory sealed to maintain the IP66 rating. There is no lamp to relamp. It is rated 60,000 hours, so for an MRO plan treat the bollard as a fixture-level replacement item rather than stocking lamps.
8) Does the 66-ARCH bollard plug in, or does it need to be hardwired by an electrician?
Hardwired. The fixture comes with a 3 ft lead wire and two gel-filled direct burial wire nuts for splicing to the supply run, and since the input is 277V this is licensed electrician work on a commercial branch circuit, not a plug-in landscape kit.
9) Should I pick 2700K or 3000K for the Archetype bollards on my property?
2700K reads warmer and closer to the look of incandescent landscape lighting, which suits residential hardscapes and planting beds. 3000K is slightly crisper and is the more common commercial walkway choice, and it tends to match neighboring exterior LED fixtures better. Both are 90 CRI. The deciding factor is usually what is already installed elsewhere on the site, since mixed Kelvin along one path is obvious at night.
10) Will the WAC Archetype bollard hold up in a coastal or de-icing-salt environment?
The housing is cast K-alloy aluminum, which WAC specifies for corrosion resistance in demanding outdoor environments, and the fixture is watertight to IP66. Bronze and black are the two finish options. In heavy salt exposure the usual field practice is to inspect and touch up the finish periodically; the functional seal is the part that keeps water out.
11) Is the WAC Archetype bollard Energy Star certified for a rebate or green building submittal?
No, the Archetype bollard is not Energy Star listed. What it does carry for a submittal is UL and cUL Listing to 1598, an IP66 wet-location rating, 90 CRI color rendering, and 10.5W total draw.
