WAC Lighting 66-TOWER Tower LED Bollard Light
The WAC Lighting 66-TOWER Tower LED Bollard Light brings a modern lighthouse silhouette to landscape and pathway lighting, topped with a mitered cut silk screened glass lens that illuminates evenly from all four sides. Cast from a special K-alloy aluminum for demanding outdoor environments, this integrated LED fixture is factory sealed and water tight with an IP66 rating against high-pressure water jets and outdoor elements. Rated for 277V AC input at 13.2W with up to 470 lumens and a 90 CRI, it delivers 60,000 rated hours of efficient illumination while carrying UL & cUL 1598 listing for wet locations.
Key Features
- Durable Construction: Cast from a special K-alloy aluminum engineered to withstand challenging outdoor environments over time, available in a bronze or black finish.
- Decorative Glass: Mitered cut silk screen glass lens diffuses light evenly from all four sides for a contemporary landscape accent.
- Electrical Rating: 277V AC input, 13.2W power draw, up to 470 lumens, 90 CRI, and 60,000 rated hours from the integrated LED module.
- Voltage Options: Available in 12V, 120V, or 277V configurations to match existing landscape lighting systems; a magnetic or electronic power supply is required (sold separately) for 12V fixtures.
- Dimmable: Smooth, continuous dimming to 10% with a Magnetic Low Voltage Dimmer (12V), Triac or ELV Dimmer (120V), or ELV Dimmer (277V).
- Weatherproof Sealing: Factory sealed and water tight with an IP66 rating, protecting against high-pressure water jets and outdoor elements.
- Mounting & Wiring: Includes a guardian spike mounting accessory and a 3ft lead wire with two gel filled direct burial wire nuts; an optional concrete pour kit is sold separately (SKU# M66-CON-KIT).
Certifications & Compliance
- UL & cUL 1598 Listed
- IP66 Rated for Wet Locations
Technical Specifications
- Bulb Base: LED Module - ACLED Module
- Bulb Shape: LED
- Bulbs Included: Yes
- Dimmable: ELV
- Energy Star: No
- Hardwired or Portable: Hardwired
- Number of Bulbs: 1
- Product Type: Bollard Lighting
- Safety Rating: UL;cUL;IP66
- Shade/Glass Description: Frosted Glass Lens
- Warranty: 5 Years Functional, 2 Years Finish
- Avg Rated Hours: 60000
- Beam Spread: Flood
- Voltage: 277
- Country of Origin: China
- Location Rating: Wet
Typical Applications
- Landscape and Garden Lighting
- Pathway and Walkway Illumination
- Commercial Outdoor Landscape Design
- Wet Location and Outdoor Installations
- Contemporary Architectural Accent Lighting
Why WAC Lighting?
WAC Lighting builds the Tower Bollard from special K-alloy aluminum with an IP66 watertight seal and UL & cUL 1598 listing for wet locations, backed by a 5-year functional and 2-year finish warranty. It's an energy-efficient, code-compliant choice for professional landscape lighting installations that need to perform reliably in demanding outdoor conditions.
Manufacturer Resources
Specification Sheet
Product Specs
- Bulb Base:
- LED Module - ACLED Module
- Bulb Shape:
- LED
- Bulbs Included:
- Yes
- Collection:
- Tower
- Dimmable:
- ELV
- Energy Star:
- No
- Hardwired or Portable:
- Hardwired
- Number of Bulbs:
- 1
- Product Type:
- Bollard Lighting
- Safety Rating:
- UL;cUL;IP66
- Shade/Glass Description:
- Frosted Glass Lens
- Subcategory:
- Bollard Light
- Avg Rated Hours:
- 60000
- Beam Spread Angle:
- Flood
- Product Voltage:
- 277
- Product Material:
- K-Alloy Aluminum
- Location Rating:
- Wet
- Total Wattage:
- 13.2
- Product Style:
- Modern
WAC Lighting 6623-27BK – Frequently Asked Questions
1) What voltage does the WAC Lighting 66-TOWER bollard run on, and can I put it on a 12V landscape transformer?
The 66-TOWER is the 277V version of the Tower bollard, drawing 13.2W. It is hardwired, not plug-in. If your site runs on a 12V low voltage landscape system or 120V line voltage, you need the 12V or 120V configuration of the Tower bollard instead. Putting a 277V fixture on a 12V transformer will not light it.
2) Can the Tower LED bollard sit in an irrigation zone or an area that gets pressure washed?
Yes. The Tower bollard is factory sealed and water tight with an IP66 rating, which covers high-pressure water jets, and it is listed for wet locations under UL and cUL 1598. Sprinkler spray and washdown are within what it is built for.
3) What dimmer works with a 277V LED bollard like the WAC Tower?
Use an ELV dimmer on the 277V Tower bollard. It dims smooth and continuous down to 10 percent. The 12V version takes a magnetic low voltage dimmer and the 120V version takes a triac or ELV dimmer, so don't carry a dimmer spec across from another voltage on the job.
4) What comes in the box with the WAC 66-TOWER bollard, and do I need anything else to install it?
It ships with a guardian spike mounting accessory, a 3ft lead wire, and two gel filled direct burial wire nuts, and the LED module is integrated so there is no lamp to buy. For a concrete base instead of spike mounting, the concrete pour kit M66-CON-KIT is sold separately. No power supply is needed at 277V; only the 12V version requires a magnetic or electronic supply.
5) Which color temperature and finish should I order for a WAC Tower bollard on a commercial walkway?
Four combinations are offered: 2700K or 3000K, each in black or bronze. 2700K reads warmer and works with traditional landscape planting and warm building facades; 3000K is slightly crisper and blends better with contemporary architecture and other 3000K site lighting. Bronze disappears against mulch and wood, black suits modern hardscape. Pick one temperature across the site so the path doesn't shift color pole to pole.
6) How does the Tower bollard throw light, and will it light a path on both sides?
Light exits through a mitered cut silk screened glass lens at the top, so it washes evenly from all four sides rather than firing one direction. The beam spread is flood, which makes it a path and area fixture, not a directional accent. Along a walkway it lights both shoulders from a single unit.
7) Can the LED be replaced in the WAC Tower bollard when it fails?
No. The Tower uses a single integrated ACLED module, factory sealed inside the housing, so there is no serviceable lamp. It is rated 60,000 hours, and at end of life you replace the fixture rather than relamp it. Plan spares that way for a large site.
8) Will a cast aluminum bollard hold up in a coastal or freeze-thaw climate?
The Tower housing is cast from a K-alloy aluminum WAC specifies for demanding outdoor environments, with the optics factory sealed to IP66. The finish is bronze or black over that casting. It is the construction you want for exposed exterior duty; corrosion life still comes down to keeping the finish intact, so avoid scraping it with edging equipment.
9) Does the WAC Tower bollard qualify as an Energy Star fixture for a rebate submission?
No, the Tower bollard is not Energy Star listed. It does carry UL and cUL 1598 listing and draws 13.2W with up to 470 lumens at 90 CRI, which is what most utility and spec review submissions actually ask for on exterior LED.
