Weslock 7110 Carlow Lever Privacy Lock with Adjustable Latch and Full Lip Strike

Weslock 7110 Carlow Lever Privacy Lock with Adjustable Latch and Full Lip Strike

(No reviews yet) Write a Review

Model: R7110H2H2SL20
From the Molten Bronze Collection
$182.00
$94.68
Selected Finish is
Selected Handing is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$182.00
$94.68
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Weslock Molten Bronze Collection, PREMIERE PRIVACY Lock

If security, safety, and style are important to you, then Weslock is your choice for quality hardware for your home. Not only are Weslock door handle and deadbolt products strong and long lasting, but they also offer a beautiful aesthetic for your home. With designs that enhance the look and feel of your home and details, such as concealed installation screws, that merge function and form, Weslock offers a product unmatched by the competition.

Privacy Function: Weslock's privacy knobs/levers feature a push button Lock on the interior for use on bedroom and bathroom doors where Locking is needed. The exterior side of this privacy knobsets/leverset features a small pin hole to unlock the knob/lever from the outside. Emergency release tool included (small pin).


Standard features

  • Cylindrical Door Locks
  • Meets ANSI A 156.2 Grade II Lock Standards
  • Removable Knobs/Levers Prevents Scratching During Installation
  • ADA compliant levers
  • Solid Molten Bronze levers, knobs, and rosettes
  • Push Button Locking in Rosette
  • Panic Proof: Yes
  • Adjustable latches 2-3/8” or 2-3/4” with removable faceplates
  • Ajusts to door thickness from 1-3/8” to 1-3/4”
  • Optional door thickness up to 2-1/4”
  • Fits doors prepared with 2-1/8” cross hole & 1” edge hole
  • Limited 10 Year Mechanical Warranty
  • Limited 5 Year Finish Warranty


Weslock Catalog

Weslock General Specifications

Installation Instruction

Manufacturer Resources

Product Specs

Product Group:
Mechanical Locks
Series:
Molten Bronze
Warranty:
Limited 10 Year Mechanical and Limited 5 Year Finish
Collection:
Molten Bronze
Cross Bore:
2-1/8"
Keyed Function:
Non-Keyed
Product Subgroup:
Bored Locksets
Product Type:
Leversets
Subcategory:
Residential Door Levers
Keyed:
No
Commercial/Residential:
Residential
Lock Function:
Privacy/Bed/Bath
Product Attribute:
Cylindrical Locks
IMAP Policy:
Yes
Backset (Distance):
2-3/8 or 2-3/4
Product Function:
Privacy/Bed/Bath
Door Thickness Range:
1-3/8" to 1-3/4"
Door Strike:
Round Corner Full Lip Strike
Product Style:
Premiere
Product Category:
Mechanical Locks
Product Substrate:
Brass
Department:
Door Hardware

Weslock R7110H2H2SL20 – Frequently Asked Questions

1) Will the Weslock 7110 Carlow privacy lever fit a door already bored for a standard lockset?
It drops into a standard residential prep: 2-1/8 inch cross bore with a 1 inch edge bore. The latch adjusts to either a 2-3/8 or 2-3/4 inch backset, so you don't have to know which backset the door was bored for before you order. Standard door thickness range is 1-3/8 to 1-3/4 inches.
2) Can the Weslock 7110 Carlow lever be used on a thick door over 1-3/4 inches?
Yes, but it is an ordering choice you make up front. The standard build covers 1-3/8 to 1-3/4 inch doors; there is a separate 1-3/4 to 2-1/4 inch door thickness option you select when ordering. Pick the wrong one and the spindle and screws won't reach on a heavy solid-core or custom door.
3) Does the Weslock 7110 Carlow privacy lever need to be ordered left hand or right hand?
Handing is a required choice on this one. The Carlow lever is sold as a Left Hand or a Right Hand set, in Oil Rubbed Bronze or Matte Black. Stand outside the door: if the hinges are on your left it's a left hand door. Order the wrong hand and the lever points the wrong way on the door.
4) How do you unlock a Weslock privacy lever from the outside if someone is locked in the bathroom?
The interior side has a push button in the rosette. Outside there's a small pin hole, and the set ships with the emergency release pin to trip it. It's also panic proof, so turning the inside lever releases the latch without unlocking first, which is what you want on a bedroom or bath door.
5) Is a dummy lever a substitute for the Weslock 7110 Carlow privacy lock?
No. The 7110 Carlow is a working cylindrical privacy lock with an adjustable latch and a round corner full lip strike, so it latches the door and locks with the push button. A dummy lever is surface trim with no latch at all. The Baldwin Estate 5103 half dummy lever with 5048 rose comes in left hand and right hand and is dummy function, and the BEST 7KC single dummy trim lever is Grade 2 dummy trim. Those go on a door that is held by a ball catch or roller catch, or on the inactive leaf of a pair, not on a bedroom or bath door that needs to lock.
6) What is the closest equivalent to the Weslock 7110 Carlow privacy lever from another brand?
The Weslock 7110 Carlow is a privacy/bed/bath cylindrical leverset for residential doors. The Kwikset 300BRNL Breton privacy lever set is the nearest match in the same function, a Grade 3 privacy/bed/bath leverset that fits doors 1-3/8 inch to 1-3/4 inch, the same standard door thickness range the Carlow covers. The Baldwin Estate 5103 privacy lever with 5048 rose is a second privacy-function lever option. The Carlow is a Grade 2 lock with solid molten bronze levers and rosettes and a push button in the rosette, so it sits above the Kwikset on the ANSI grade while matching it on opening type.
7) What privacy lever should I use on a commercial bathroom door instead of the Weslock 7110 Carlow?
The Weslock 7110 Carlow is built for residential openings. For a commercial restroom, the Arrow MK02-TA is a privacy/bed/bath cylindrical lock rated Grade 1 with a fire rating and a Tudor knob, and it fits doors 1-3/4 inch to 2 inch. The Hager 2540 is a Grade 2 privacy cylindrical lock with the Withnell lever for doors 1-3/8 inch to 2 inch, which keeps the lever pull the Carlow gives you. The Arrow is a knob rather than a lever, so on an opening where ADA lever operation is required the Hager is the one that carries it over.
8) Will a lever that only fits 1-3/4 inch doors work where I would put the Weslock 7110 Carlow?
Not always. The 7110 Carlow adjusts to door thickness from 1-3/8 inch to 1-3/4 inch as standard, with an option that takes it up to 2-1/4 inch, so it covers thin residential doors that some commercial levers do not. The Design Hardware J75 and X75 passage levers are listed for 1-3/4 inch doors only, and the Arrow GL01 Sierra lever passage lock covers 1-3/4 inch to 2 inch - none of those will pick up a 1-3/8 inch interior door. The Dexter C1000 entry/office and classroom levers and the Cal-Royal AG05 storeroom lever all cover 1-3/8 inch to 1-3/4 inch, so they match the Carlow's standard range.
9) What strike comes with the Weslock 7110 privacy lever, and will it match my existing frame prep?
It ships with a round corner full lip strike. That suits a wood frame mortised with a radius-corner router prep, which is the common residential case. If your frame has a square-corner strike cutout or a T-strike in hollow metal, the included plate won't drop straight in.
10) Do I have to know my backset before ordering the Weslock 7110 lever?
No. The latch adjusts between 2-3/8 and 2-3/4 inches, which are the two backsets used on residential doors, and the faceplates are removable so the latch suits either prep. That makes it a safe pick when you're replacing hardware across a building and haven't measured every door.
11) I need the same Carlow lever on a hall or closet door where no lock is wanted - what changes?
The Weslock 7110 Carlow is privacy function with a push button lock in the rosette, so it is not the right pick for a door that should never latch closed against someone. For a hall or closet in the same residential range, the Kwikset 200BRNL Breton passage lever set is Grade 3 passage/hall/closet for doors 1-3/8 inch to 1-3/4 inch, and the Baldwin Estate 5103 passage lever with the 5048 rose is a passage version of the same 5103 trim as the Baldwin privacy. On the commercial side the Falcon B101 is a Grade 2 medium duty passage lever with a non-handed design, which removes the left hand or right hand decision the Carlow requires.
12) What do I use instead of the Weslock 7110 Carlow when the bedroom door also needs a key?
The 7110 Carlow is non-keyed - it is a push button privacy lock with a small pin hole for emergency release from the outside, and the release pin is included. When the opening needs a key from the outside instead, the Cal-Royal AG00 is an entrance lever with a 6-pin Schlage C keyway keyed different on a 2-3/8 inch backset for doors 1-3/8 inch to 1-3/4 inch, matching one of the two backsets the Carlow adjusts to. The Falcon B511CP6D is a Grade 2 medium duty entry/office lever for the same job on a commercial door.
13) Can I put the Weslock 7110 Carlow on a patient room or utility door?
The 7110 Carlow is a residential privacy lever that unlocks from the outside through a pin hole with the included emergency release tool. For an asylum or institutional opening where the door must be controlled by key from both sides, the Dexter C1000 series asylum lock is Grade 1 F87 asylum function for doors 1-3/8 inch to 2 inch, and the Arrow MK33-BD-CS is a Grade 2 heavy duty asylum lock with a ball knob and a conventional cylinder in the Schlage C keyway. Those carry cylinders on both faces; the Carlow has none.
14) Is the Weslock Carlow lever solid brass or hollow tube?
Solid molten bronze levers, knobs and rosettes, on a brass substrate. That is the weight difference you feel against a stamped or tubular residential lever, and it is the reason the Molten Bronze line holds up in oil rubbed bronze and matte black finishes on doors that get used every day.
15) Will installation screws show on the face of the Weslock Carlow lever?
No. The Molten Bronze trim uses concealed installation screws, so the rosette face is clean. The levers also come off for install, which keeps them from getting scratched while you're setting the rose and driving screws.
16) Is there a keypad lever I can use in place of the Weslock 7110 Carlow?
The 7110 Carlow is a mechanical push button privacy lock with no code entry. If the opening needs code access instead, the Delaney LP250 is a Grade 2 electronic keypad leverlock, the Emtek Classic keypad leverset is a decorative keypad option, and the Lockey 1150 is a heavy duty mechanical keypad lever set with double combination in passage function for doors 1-1/8 inch to 2 inch. A keypad lever is an access control device for a door people are let through, not a bed and bath privacy latch, so the two are not interchangeable on the same opening.
17) I want the decorative look of the Weslock Carlow but on a passage door - what other decorative lever lines match?
The Weslock 7110 Carlow is a Molten Bronze collection lever with solid brass substrate, concealed installation screws, and removable levers, offered in oil rubbed bronze and matte black. For decorative trim in other lines, the Baldwin Estate 5103 with 5048 rose runs in passage, privacy, and left and right hand half dummy so one lever design covers a whole floor. Emtek's Arts and Crafts leversets offer the Arts and Crafts lever and the Hammered lever in dummy pairs, and the Classic Brass Cortina lever comes as a dummy pair for closet and inactive doors.
