Weslock 7300 Carlow Lever Squa...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$182.00
$94.68
Weslock 7300 Carlow Lever Square Passage Lock with Adjustable Latch and Full Lip Strike

Weslock 7300 Carlow Lever Square Passage Lock with Adjustable Latch and Full Lip Strike

(No reviews yet) Write a Review

Model: R7300H1H1SL20
From the Molten Bronze Collection
$182.00
$94.68
Selected Finish is
Selected Handing is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$182.00
$94.68
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Weslock Molten Bronze Collection, SQUARE Passage Lock

If security, safety, and style are important to you, then Weslock is your choice for quality hardware for your home. Not only are Weslock door handle and deadbolt products strong and long lasting, but they also offer a beautiful aesthetic for your home. With designs that enhance the look and feel of your home and details, such as concealed installation screws, that merge function and form, Weslock offers a product unmatched by the competition.

Passage: Passage door hardware has no Locking mechanism. Both the interior and exterior handles are always free making it perfect for hallways, closet doors, and anywhere else a Lock isn't needed. Passage door hardware can also be used in conjunction with a deadbolt to secure a back door or entrance.


Standard features

  • Cylindrical Door Locks
  • Meets ANSI A 156.2 Grade II Lock Standards
  • Removable Knobs/Levers Prevents Scratching During Installation
  • ADA compliant levers
  • Solid Molten Bronze levers, knobs, and rosettes
  • Push Button Locking in Rosette
  • Adjustable latches 2-3/8” or 2-3/4” with removable faceplates
  • Ajusts to door thickness from 1-3/8” to 1-3/4”
  • Optional door thickness up to 2-1/4”
  • Fits doors prepared with 2-1/8” cross hole & 1” edge hole
  • Limited 10 Year Mechanical Warranty
  • Limited 5 Year Finish Warranty


Weslock Catalog

Weslock General Specifications

Installation Instruction

Manufacturer Resources

Product Specs

Product Group:
Mechanical Locks
Series:
Molten Bronze
Warranty:
Limited 10 Year Mechanical and Limited 5 Year Finish
Collection:
Molten Bronze
Cross Bore:
2-1/8"
Keyed Function:
Non-Keyed
Product Subgroup:
Bored Locksets
Product Type:
Leversets
Subcategory:
Residential Door Levers
Keyed:
No
Commercial/Residential:
Residential
Lock Function:
Passage
Product Attribute:
Cylindrical Locks
IMAP Policy:
Yes
Backset (Distance):
2-3/8 or 2-3/4
Product Function:
Passage/Hall/Closet
Door Thickness Range:
1-3/8" to 1-3/4"
Door Strike:
Round Corner Full Lip Strike
Product Style:
Square
Product Category:
Mechanical Locks
Product Substrate:
Brass
Department:
Door Hardware

Weslock R7300H1H1SL20 – Frequently Asked Questions

1) Does a passage lever lock, or do I need a privacy set for a bedroom or bath?
Passage function means no lock at all. Both levers stay free at all times, which is what you want on a hallway, closet, or pantry. For a bedroom or bathroom you need a privacy set with a push button instead. On a back door, a passage set paired with a separate deadbolt handles the security side.
2) Do I have to order the Weslock Carlow passage lever left hand or right hand?
Yes, handing is specified at order. The Carlow lever comes left hand or right hand in both finishes, so stand outside the door and note which side the hinges are on before ordering. Passage levers have no keyed side, but the lever still has to point the right way.
3) Is the Weslock 7300 Carlow lever rated for a commercial building or an apartment corridor?
It is a residential lockset, ANSI A156.2 Grade 2. Fine for a single-family home or an in-unit door. For corridors, offices, or anything on a heavy traffic commercial opening, step up to a Grade 1 cylindrical passage lever like the Falcon K101 or the Corbin Russwin CL3110, both Grade 1 passage function.
4) I need a fire rated passage lever for a rated door. Is this the right one?
No. Look at a Grade 1 passage lever with a stated fire rating instead. The Falcon K101 and the Corbin Russwin CL3110 are both cylindrical passage locks that carry a fire rating in our specs, and the K101 covers doors from 1-3/8 to 2-1/4 inches thick.
5) Is a dummy lever the same as the Weslock 7300 Carlow passage lock?
No. The Weslock 7300 Carlow is a cylindrical passage lock with a working latch, an adjustable 2-3/8 or 2-3/4 inch backset latch and a round corner full lip strike, so it latches the door shut. A dummy lever is surface trim with no latch and no operation - the Baldwin Estate 5103 Half Dummy is offered in left hand and right hand, the BEST 7KC single dummy trim is a Grade 2 non-keyed cylindrical lever trim, and the Emtek Arts and Crafts dummy is sold as a pair. Order dummy trim only for an inactive leaf or a door held by a ball catch, not for a hall or closet door that needs to latch.
6) What is a direct commercial equivalent to the Weslock 7300 Carlow passage lever?
The Weslock 7300 Carlow is a non-keyed cylindrical passage lever with a passage/hall/closet function, catalogued for residential use. For a commercial-graded equivalent in the same function, the Falcon B101 is a Grade 2 cylindrical passage lever lock with a non-handed design, and the Accentra 5301LN Augusta is a Grade 2 cylindrical lever lock in passage/closet function. Both keep the same always-free, no-locking operation the 7300 provides, with a commercial grade rating on the carton for a spec that calls for one.
7) What passage lever should I use on a high-traffic corridor door instead of the Weslock 7300 Carlow?
The Weslock 7300 Carlow is a residential cylindrical passage lever. For corridor and stairwell traffic, the Falcon K101 is a Grade 1 heavy duty passage cylindrical lock with non-handed levers, carries a fire rating, and covers a door thickness range of 1-3/8 inch to 2-1/4 inch. The Falcon T101 is also a Grade 1 heavy duty cylindrical passage lever, and the Corbin Russwin CL3110 is a Grade 1 vandal resistant passage/closet lever with a fire rating. Any of the three answers a Grade 1 line on a drawing that the 7300 does not.
8) I need a lock for a bedroom or bathroom door, not a hall door. What replaces the Weslock 7300 Carlow there?
The Weslock 7300 Carlow is a passage lever with no locking mechanism, so both levers are always free - wrong for a bath or bedroom that needs to be secured from the inside. Use a privacy function instead: the Baldwin Estate 5103 Privacy Lever with 5048 Rose, the Hager 2540 privacy cylindrical lock with Withnell lever covering 1-3/8 inch to 2 inch doors, or the Kwikset 300BRNL RDT Breton privacy lever set, a Grade 3 privacy lock for 1-3/8 inch to 1-3/4 inch doors.
9) The door needs to lock with a key. What do I order instead of the Weslock 7300 Carlow?
The Weslock 7300 Carlow is a non-keyed passage lever, so it takes no cylinder at all. For a keyed opening, the Hager 2525 is a Grade 2 commercial cylindrical entry lock with a lever handle for 1-3/8 inch to 2 inch doors, the Cal-Royal AG00 is a Grade 2 entrance lever with a 6-pin Schlage C keyway keyed different and a 2-3/8 inch backset, and the Dexter C1000 entry/office is a Grade 1 keyed cylindrical lever with clutching. For a storeroom opening where the outside lever stays locked at all times, the Cal-Royal AG05 is a Grade 2 storeroom leverset with a deadlocking latchbolt.
10) Does the Weslock 7300 Carlow meet a Grade 1 passage spec, or do I need a different lock?
The Weslock 7300 Carlow meets ANSI A156.2 Grade 2 lock standards and uses ADA compliant levers. Where the drawing calls for Grade 1 in passage function, the Design Hardware X75 is a Grade 1 passage lever lockset with a flat lever for 1-3/4 inch doors, and the Falcon T101 is a Grade 1 heavy duty cylindrical passage lever. The Design Hardware J75 is the Grade 2 flat-lever passage counterpart if Grade 2 is acceptable.
11) I ordered the Weslock 7300 Carlow for an exterior door. Is that the right lock?
The Weslock 7300 Carlow is a passage lock with no locking mechanism, intended for hallways, closets, and anywhere a lock is not needed, though it can be used with a separate deadbolt to secure a back door. If you want the lever itself to lock, choose an entry function instead: the Deltana 6201 Manchester and 6411 Morant are entry levers covering 1-3/8 inch to 2 inch doors, the Callan Artino is a Grade 3 entrance leverset, and the Callan Bennett is a Grade 3 entrance leverset with a deadbolt combo so the lever and deadbolt arrive together.
12) What finishes does the Weslock 7300 Carlow square lever come in?
Two finishes: Oil Rubbed Bronze and Matte Black, each available in left or right hand. Both are on solid molten bronze levers and rosettes rather than plated steel, and the trim is a square rose to match a squared lever profile. If the rest of your doors are on satin nickel or brass, this pair will not match.
13) Does the Weslock Carlow passage lever come with a strike, and will it match my existing frame cutout?
A round corner full lip strike ships with the lockset. That is the strike used on most prehung wood frames with a radius mortise. If your jamb has a square-cornered strike mortise or a T-strike, the round corner plate will not sit flush without reworking the jamb.
14) Are the Weslock Carlow levers ADA compliant?
The levers are ADA compliant, meaning they operate without grasping, pinching, or twisting the wrist. That is the point of a lever over a knob on an accessible route. The passage function helps here too, since there is nothing to unlock.
15) What else could I use instead of the Weslock Carlow if I want a squared-off passage lever?
The Bravura Tampa is a Grade 2 passage leverset with square trim, the closest match in shape. If you want a round rose instead, the Bravura Atlanta, Orlando, and Miramar are all Grade 2 passage leversets. On the residential side, the Kwikset 200BRNL Breton is a Grade 3 passage lever covering 1-3/8 to 1-3/4 inch doors.
16) I'm standardizing hardware across a building. Can I match the Weslock Carlow passage lever with privacy and keyed sets in the same trim?
The Carlow square lever belongs to the Weslock Molten Bronze collection, which is built as a family across functions, so the trim and finish carry over between the passage, privacy, and entry sets in that collection. Order the same collection and finish across the openings and only the function changes. The bore stays the same throughout at 2-1/8 inch cross bore and 1 inch edge bore, so the door prep is identical door to door.
17) What passage lever fits a 2 inch thick door if the Weslock 7300 Carlow does not?
The Weslock 7300 Carlow covers 1-3/8 inch to 1-3/4 inch as standard with an optional thickness up to 2-1/4 inch. If you are ordering a single stock set for thicker leaves, the Hager 2510 is a Grade 2 passage cylindrical lever with a Withnell design covering 1-3/8 inch to 2 inch, the Arrow GL01 is a Grade 2 Sierra lever non-keyed passage lock for 1-3/4 inch to 2 inch doors, and the Corbin Russwin CL3110 passage/closet lever covers 1-3/4 inch to 2 inch. Confirm the leaf thickness before you choose, since the Arrow and Corbin ranges start at 1-3/4 inch.
18) I want a square-trim passage lever to match other square hardware. What matches the Weslock 7300 Carlow style?
The Weslock 7300 Carlow is a square style lever in the Molten Bronze collection, offered in oil rubbed bronze and matte black in both left hand and right hand. If you are matching square trim across a set of doors, the Bravura Tampa is a Grade 2 passage leverset with square trim. Round-trim passage leversets in the same function include the Bravura Atlanta, Orlando, and the Miramar in US4 satin brass, all Grade 2 - useful if the rest of the openings run round rosettes instead.
19) Can I put the Weslock 7300 Carlow on a door that needs keypad or code entry?
No. The Weslock 7300 Carlow is a non-keyed passage lever with no locking mechanism, so it accepts no cylinder and no code. For code entry on a lever, the Lockey 1150 is a heavy duty mechanical keypad lever set with double combination in passage function for doors 1-1/8 inch to 2 inch thick, the Delaney LP250 is a Grade 2 electronic keypad leverlock, and Emtek offers a Classic keypad leverset. The Lockey is mechanical, so it needs no power at the door.
20) What passage lever works in a classroom or institutional building where the Weslock 7300 Carlow would not be specified?
The Weslock 7300 Carlow is a residential Grade 2 passage lever. In schools and institutional facilities, the passage openings usually pair with keyed functions from the same commercial line: the Dexter C1000 Grade 1 classroom cylindrical lever is clutching and keyed, the C1000 classroom security version covers doors 1-3/8 inch to 1-3/4 inch, and the Dexter C1000 asylum function fits utility and institutional doors 1-3/8 inch to 2 inch. For the hall doors themselves, the Corbin Russwin CL3110 Grade 1 vandal resistant passage lever is fire rated.
21) Can I get the Carlow lever as a dummy for a closet door that doesn't latch?
The 7300 Carlow is a working passage set with a live latch, not a dummy trim. For a surface-mounted lever with no latch at all, look at the Baldwin Estate 5103 half dummy, offered in left and right hand, or the Baldwin Estate 5103 in passage if you do want the latch. Dummy trim is handed too, so pick the side.
22) Will the mounting screws show on the face of the Weslock Carlow rose?
No, the installation screws are concealed behind the rosette, so the finished face is clean on both sides. The levers also come off for installation, which keeps the finish from getting scratched while you drive the through-bolts and set the latch.
23) Is the Weslock Carlow lever solid brass or a plated hollow lever?
Solid molten bronze levers, knobs, and rosettes, on a brass substrate. That is the difference you feel in the hand versus a stamped or tubular residential lever, and it is why the Oil Rubbed Bronze finish wears the way it does over time rather than flaking off a thin plating.
