Wood Bit Quik-Bit Flat 9/16" 16" (1pc)
Manufacturer Resources
Product Specs
- Division:
- Electrical H1
- Pack Type:
- Pouch
- Product Group:
- Fasteners
- Sub Division:
- Electrical-E H2
- Department:
- Electrical
- Product Subgroup:
- Screws
Metallics QB25 – Frequently Asked Questions
1) What size hole does the Metallics QB25 Quik-Bit drill, and how long is it?
The QB25 is a 9/16 inch flat wood boring bit with a 16 inch overall length. The 9/16 inch cut is the common size electricians use for running cable through studs and joists, and the 16 inch length lets you reach through a stud bay or bore several framing members in line without an extension.
2) Is the 9/16 inch Quik-Bit big enough to pull 12/2 or 14/2 NM cable through studs?
A 9/16 inch hole is the size most electricians drill for pulling single runs of 14/2 or 12/2 NM through wood studs and joists, and the QB25 cuts exactly that. If you need to pull two or three cables through the same hole, step up to a larger bit so the jacket is not scraped on the pull.
3) Is the Metallics QB25 a spade bit or an auger bit?
It is a flat (spade/paddle) wood bit, not an auger. A spade bit like the QB25 clears fast in soft framing lumber and costs less to replace when it hits a nail, but it does not self-feed the way an auger does, so you push it through. For deep boring through engineered lumber or stacked plates, a self-feeding auger is the better tool.
4) Can I use the Metallics QB25 on metal studs?
No. It is a wood bit, cut for soft framing lumber, and the spade geometry will dull or grab in steel. For metal studs use a step bit or a hole saw rated for sheet steel, and bush the opening before pulling cable.
5) How many bits come in a Metallics QB25 pack?
One bit per pack, supplied in a pouch. If you are drilling a full rough-in and expect to burn through bits on nail plates or hidden fasteners, order multiples rather than assuming a set.
How fast can I get the Metallics QB25 delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the
continental
U.S.
Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit,
reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Metallics QB25 come with a warranty?
Absolutely. The Metallics QB25 is backed by a manufacturer’s warranty.
For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Metallics QB25?
You can call, text, or email our expert support team for fast answers. We’re here to help with
product
selection,
installation tips, and troubleshooting. Contact Us
Why buy the Metallics QB25 from ZenSupply?
ZenSupply makes it easy to get the commercial door hardware you need—fast shipping, expert support,
and
rewards on
every order.
Our team is always ready to help you choose the right product for your project.
