Metallics JPMP38 12-24 x 3/4 in. Pan Head Phillips Machine Screws - Steel Zinc - 100qty

Metallics JPMP38 12-24 x 3/4 in. Pan Head Phillips Machine Screws - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JPMP38
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.43
$0.43
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
12-24 x 3/4 in. Pan Head Phillips Machine Screws - Steel Zinc - 100qty

  • Additional Notes

    • Other sizes and quantities available by request | Tensile strength values for stainless screws are offered as approximations only; there is no single standard for the performance requirements of stainless machine screws.

  • Features

    • Steel Zinc Material
    • Pan head with Phillips Drive
    • 12-24 Diameter, 3/4" Length

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
C
Buy American Compliant:
C
Dimensional Standard:
ASME B18.6.3-2010
Division:
Electrical H1
Drive Type:
Phillips
Driver Size:
#3
Fastener Head Color:
Silver
Fastener Head Height:
0.139 - 0.151 in.
Fastener Head Type:
Pan
Fastener Head Width:
0.407 - 0.425 in.
Fastener Length:
4-Mar
Hardness:
Rockwell B70-B100
Language Code:
EN
Material Standard:
AISI 1006 - 1022
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Pan_Head_Screw_St_SS.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
CT
Pack Type:
Jar
Phillips Recess Diameter:
0.252
Product Group:
Fasteners
Product Height:
2.7 in
Product Length:
3 in
Product Weight:
1 lbs
Product Width:
3 in
Recess Penetration Gaging Depth:
0.098 - 0.124
Sub Division:
Electrical-E H2
Tensile Strength:
60000 psi minimum
Thread Per Inch:
24
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Machine Screw
Type2:
Machine Screw
Series:
PMP
Product Finish:
Zinc
Product Details:
Machine Screw
Product Material:
Steel Zinc

Metallics JPMP38 – Frequently Asked Questions

1) Do these machine screws meet Buy American and ARRA requirements for a government job?
The JPMP38 is flagged both ARRA compliant and Buy American compliant in the manufacturer data, with country of origin listed as multiple. Institutional and federally funded projects asking for that documentation are covered on this item.
2) What size Phillips driver do I need for these 12-24 pan head screws?
A #3 Phillips bit. The recess is 0.252 inch in diameter with a gaging depth of 0.098 to 0.124 inch, so a #2 bit will sit shallow and cam out under torque. Keep a #3 in the pouch if you are running these by drill.
3) How much clearance does the pan head take up on a cover plate or bracket?
Head height runs 0.139 to 0.151 inch with a head width of 0.407 to 0.425 inch. That is a low, broad bearing surface, so it seats flat on sheet metal and slotted brackets without needing a washer, but it does stand proud of the surface. If you need the head flush, a pan head is the wrong profile.
4) Are these zinc plated steel screws suitable for outdoor or damp locations?
These are zinc plated carbon steel, made to AISI 1006 to 1022 material. Zinc plating handles dry interior work, panel interiors, and conditioned spaces. For wet locations, washdown areas, or coastal exposure, specify a stainless machine screw instead; the plating will eventually give up in standing moisture.
5) What dimensional standard do these pan head Phillips screws conform to?
Dimensions follow ASME B18.6.3-2010, the standard for machine screws and tapping screws. If a submittal or drawing calls out B18.6.3 pan head Phillips, this screw answers that line. Hardness is Rockwell B70 to B100 with a 60,000 psi minimum tensile.
6) How are Metallics JPMP38 screws packaged and what is the minimum I can buy?
They come in a jar of 100, and 100 count is the order minimum. Good for a service van or a shop bin rather than a single repair. Other sizes and quantities are available by request if the job needs a different length.
7) Will these screws match the finish on existing silver hardware?
The head is silver, from the zinc plating over steel, so it blends with mill-finish steel brackets, galvanized boxes, and plated device hardware. It will not match brass, black, or painted trim.
