ACSI K-132 Adams Rite EX76, EX76W, EX88, EX88W Series

ACSI K-132 Adams Rite EX76, EX76W, EX88, EX88W Series

(No reviews yet) Write a Review

Model: K-132
From the 1500 Series Collection

In Stock (leaves warehouse same day if ordered before 3pm ET)

$90.00
$56.63
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

ACSI K-132 Adams Rite EX76, EX76W, EX88, EX88W Series

  • K-131 Request To Exit Switch Kit for Falcon 1690, 1790 Series. ACSI Series K Switch Kits are field installed in exit devices. Series K Switch Kits include a SPDT (Single Pole Double Throw) switch assembly with long wire leads and easy-to-follow installation instructions. K Switch Kits may be used to:
  • Provide instant release of magnetic locks for free egress.
  • Activate a door alarm.
  • Signal a control console when the push bar of an exit device is depressed.
  • Shunt a door alarm to allow free egress.
  • Buy the ACSI K-131 Switch Kit for Falcon 1690, 1790 Series for easy installation and dependable door hardware solution.

ACSI K-132 Adams Rite EX76, EX76W, EX88, EX88W Series

PRODUCT FEATURES

  • Function: Part/Component
  • Product Type: Access Control Part/Accessory
  • ADA Compliant: No
  • Contact Ratings: 3A @ 125VAC; 2A @ 30VDC
  • Function Family: Part/Component
  • Features: SPDT Monitor Switch; Authorized Egress
  • For Use With: Falcon 1690 and 1790 Series; First Choice 3600 and 3700 Series
  • Manufacturer Parent: ACSI
  • Sub-Series: K-131

ACSI ELECTRIC EXIT DEVICE SWITCH KITS COLLECTION

  • ACSI ACSI K-100 Request To Exit Switch Kit for Von Duprin 33A, 35A, 98, 99 Series
    ACSI K-200 Request To Exit Switch Kit for Von Duprin 33A, 35A, 98, 99 DPDT Series
    ACSI K-101 Request To Exit Switch Kit for Von Duprin 55 Series
    ACSI K-102 Request To Exit Switch Kit for Von Duprin 88 Series
    ACSI K-103 Request To Exit Switch Kit for Sargent 80 Series Series
    ACSI K-203 Request To Exit Switch Kit for Sargent 80 Series DPDT Series
    ACSI K-104 Request To Exit Switch Kit for Sargent 9600, 9700, 9800, 9900 Series
    ACSI K-105 Request To Exit Switch Kit for Sargent 9300, 9400, 9500 Series
    ACSI K-106 Request To Exit Switch Kit for Adams Rite 8000, 3000 Series
    ACSI K-107 Request To Exit Switch Kit for Corbin Russwin 8000 and Yale 2100 Series
    ACSI K-108 Request To Exit Switch Kit for Jackson 1085, 1095 Series
    ACSI K-109 Request To Exit Switch Kit for Yale 7000 and Corbin Russwin ED4000, ED5000 Series
    ACSI K-110 Request To Exit Switch Kit for Monarch 18, 19 Series
    ACSI K-111 Request To Exit Switch Kit for Doromatic 990, 1090 Series
    ACSI K-112 Request To Exit Switch Kit for Doromatic 1490, 1590 Series
    ACSI K-124 Request To Exit Switch Kit for Precision 2000 Series Series
    ACSI K-125 Request To Exit Switch Kit for Dorma 9000 Series
    ACSI K-126 Request To Exit Switch Kit for Hager 4500, 4600 and PDQ 6200 and Stanley Commercial QED100, 200, 300 Series
    ACSI K-226 Request To Exit Switch Kit for Hager 4500, 4600 and PDQ 6200 and Stanley Commercial QED100, 200, 300 DPDT Series
    ACSI K-128 Request To Exit Switch Kit for Design 1000 Series
    ACSI K-129 Request To Exit Switch Kit for Falcon 24, 25 Series
    ACSI K-130 Request To Exit Switch Kit for Jackson 20 Series
    ACSI K-131 Request To Exit Switch Kit for Falcon 1690, 1790 Series
    ACSI K-123 Latch Bolt Monitor Switch Kit for Von Duprin 33A, 35A, 98, 99 Series
    ACSI K-127 Latch Bolt Monitor Switch for ACSI 1500K-VD ELR Kit on Von Duprin 33A, 35A. 98, 99 Series

Product Specs

Subcategory:
Electric Exit Device Switch Kits
Series:
1500 Series
Collection:
1500 Series
Product Type:
Exit Device Field Install Kits
Compatibility:
Adams Rite EX76, EX76W, EX88, EX88W Series
Commercial/Residential:
Commercial
Electronic:
Yes
Lock Function:
Part/Component
Product Group:
Electronic Access Controls
Product Subgroup:
Sensors, Switches, Relays and Timers
Product Function:
Part/Component
Fire Rating:
No
Product Category:
Electronic Access Control
Department:
Door Hardware

ACSI K-132 – Frequently Asked Questions

1) Which exit devices does the ACSI K-132 switch kit fit?
The K-132 is built for Adams Rite EX76, EX76W, EX88, EX88W series exit devices. It is one kit in a family where each part number targets a specific device line, so a kit made for another manufacturer's device will not drop into an Adams Rite EX76 or EX88 chassis. If you are working on Adams Rite 8000 or 3000 series devices instead, the K-106 is the kit for those.
2) What does a request to exit switch kit in an exit device actually do?
It gives the access control system an electrical signal the moment the push bar is pressed. Typical uses are instant release of magnetic locks for free egress, triggering a door alarm, shunting a door alarm so egress does not cause a nuisance trip, and signalling a control console that the bar was depressed. The ACSI Series K kits are field installed inside the exit device rather than mounted on the frame.
3) What type of switch and contact rating comes in the ACSI Series K exit device kit?
A SPDT (single pole double throw) switch assembly with long wire leads, rated 3A at 125VAC and 2A at 30VDC. The double throw contacts give you both a normally open and a normally closed set off one switch, so it can release a mag lock and shunt an alarm at the same time. Keep any relay or mag lock load inside those ratings, or switch the load through an interposing relay.
4) Can I add request to exit switching to an Adams Rite EX76 that is already installed, or do I have to buy a new electrified device?
No new device needed. The Series K kits are field install kits, so the switch goes into the exit device on the opening as a retrofit. Plan on pulling the push bar cover to route the leads and get the wiring out of the door, which on a mag lock job usually means a door cord or electric hinge if there is not already a transfer in place.
5) Is this an add-on kit or a complete exit device?
It is a component kit only, not a device. You are buying a switch assembly with wire leads and installation instructions that goes into an exit device you already have on the door. The exit device, the power supply, and any mag lock or alarm panel it signals are separate.
6) I am standardizing request to exit switches across a building with mixed exit device brands. Does ACSI cover the other devices too?
Yes, the Series K line is organized by device family so one switch platform covers a mixed building. Examples: K-100 for Von Duprin 33A, 35A, 98, 99; K-103 for Sargent 80; K-104 for Sargent 9600, 9700, 9800, 9900; K-109 for Yale 7000 and Corbin Russwin ED4000, ED5000; K-125 for Dorma 9000; K-124 for Precision 2000; K-131 for Falcon 1690, 1790. Order by the device on each opening, not by a single part number for the whole job.
7) What is the difference between an SPDT kit like this and the DPDT versions ACSI lists?
Single pole double throw gives you one common with a normally open and a normally closed contact, enough for one function such as releasing a mag lock or shunting an alarm. The DPDT kits, like the K-200 for Von Duprin 33A, 35A, 98, 99 or the K-203 for Sargent 80, give two independent sets of contacts so you can drive two separate circuits that must stay electrically isolated, for example a mag lock release on one and a monitoring input on the other.
8) Is a request to exit switch the same thing as a latch bolt monitor?
No, and mixing them up is a common spec error. A request to exit switch signals when the push bar is depressed, which is what you use to release a mag lock or shunt an alarm. A latch bolt monitor reports whether the latch is actually thrown and secure, which is what a monitoring system wants for door status. ACSI sells those separately, such as the K-123 latch bolt monitor kit for Von Duprin 33A, 35A, 98, 99. If you need both functions you order both kits.
9) Is the ACSI K-132 fire rated or ADA compliant?
No on both counts. The K-132 carries no fire rating, and it is not an ADA compliant item in its own right. It is a switch component, so those attributes are governed by the exit device and opening it goes into, not by the kit.
