Aiphone Aiphone JPS-4AED - 7" Touchscreen Video Intercom Set (JP-DA, JP-4MED, PS-2420UL) JPS-4AED

Aiphone JPS-4AED - 7" Touchscreen Video Intercom Set (JP-DA, JP-4MED, PS-2420UL)

(No reviews yet) Write a Review

Model: JPS-4AED

In Stock (leaves warehouse same day if ordered before 3pm ET)

$3,080.00
$2,227.63
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

The JP-DA is a surface mount door station used with the JP hands-free, color video entry series. The unit mounts to a 1-gang box and is made from sturdy ABS plastic with a clear polycarbonate lens cover. The JP-DA features a color 1/4" CMOS camera, speaker and mic for communication, illuminated call button and white illumination LED for low light conditions.

The JP-4MED is a video master station with a 7" color touchscreen LCD. The JP-4MED offers handset (duplex) and hands-free (VOX) communication. This unit will support up to 4 door stations and 7 sub-masters. All inside stations are equipped with a door release button for the user to allow visitor entry.

The PS-2420UL is a DC 24V Class II power supply used for Aiphone intercom applications. This power supply is UL and CSA listed and is designed for indoor use only.

FEATURES

  • Open voice hands-free auto-voice actuation
  • Handset Simultaneous Communication
  • Room-to-room communication
SPECS
  • Type of communication: Open voice hands-free auto-voice actuation, Handset Simultaneous Communication
  • Camera Type: 1/4" CMOS
  • Viewing Angle: Wide (approx. 100° x 170°) with Digital Pan, Tilt, and Zoom
  • Wire Type for Door Station to Master Station: 2 cond., mid cap, solid, non shielded - use Aiphone #871802
  • Wire Type for Power Supply to Master Station: 2-cond., mid cap, solid, non shielded - use Aiphone #871802
  • Wire Distance from Door Station to Master Station: 165' (22AWG), 330' (18AWG)
  • Wire Distance from Power Supply to Master Station: 16'(22AWG) 33'(18AWG)

Manufacturer Resources

JP-4MED Brochure

Product Specs

Product Type:
Video Intercom Box Sets
Series:
JP Series
Product Group:
Electronic Access Controls
Product Subgroup:
Intercoms
Subcategory:
Video Intercoms
Commercial/Residential:
Commercial
Electronic:
Yes
Product Category:
Electronic Access Controls
Department:
Door Hardware

Aiphone JPS-4AED – Frequently Asked Questions

1) What comes in the Aiphone JPS-4AED video intercom set?
Three pieces ship together: the JP-DA surface mount door station, the JP-4MED 7 inch color touchscreen master station, and the PS-2420UL 24V DC Class II power supply. That covers one entry and one inside answering point. Wire is not part of the set, and the JP-DA mounts to a 1-gang box, so you supply the box and cable.
2) How far can I run the wire from the Aiphone JP-DA door station to the master station?
165 feet on 22AWG, or 330 feet on 18AWG. The run from the power supply to the master station is much shorter: 16 feet at 22AWG, 33 feet at 18AWG, so plan on mounting the PS-2420UL close to the JP-4MED and pulling the longer run out to the door. Both runs use 2-conductor, mid cap, solid, non-shielded wire (Aiphone #871802).
3) Can I add more doors or a second inside station to the Aiphone JP-4MED?
Yes. The JP-4MED master supports up to 4 door stations and 7 sub-masters, so a building with a front entry, a rear entry and a garage door can run off one master, with additional inside stations added where staff or tenants need to answer. Those extra stations are ordered separately; the JPS-4AED set covers one door and one master.
4) Can visitors be let in from the intercom, or do I still have to walk to the door?
Every inside station in the JP series is equipped with a door release button, so whoever answers the JP-4MED can release the entry without leaving the desk. That is the reason property managers and front-office staff use this set over a plain audio intercom. The actual lock or strike at the door is a separate item and is not part of the set.
5) Is the Aiphone JP-DA door station rated for outdoor mounting?
The JP-DA is a surface mount station in ABS plastic with a clear polycarbonate lens cover over the camera. The PS-2420UL power supply packed with it is designed for indoor use only, so mount the supply inside, in a closet or equipment room, and keep it out of an exterior location.
6) How much of the entry can you actually see on the Aiphone JPS-4AED camera?
The JP-DA uses a 1/4 inch CMOS color camera with a wide viewing angle of roughly 100 by 170 degrees, plus digital pan, tilt and zoom from the touchscreen. That spread is wide enough to pick up a delivery left on the ground or a second person standing off to the side of the door, and the digital PTZ lets the operator push in without re-aiming the camera.
7) Does the Aiphone JP-4MED work hands-free or do you need to pick up a handset?
Both. The JP-4MED does open voice hands-free with auto-voice actuation (VOX), and it also supports handset simultaneous (duplex) communication when you want a private, two-way-at-once conversation. It handles room-to-room calling between inside stations as well, which is what makes it usable as a small office or front-desk intercom and not just a door answer point.
8) Is the Aiphone JPS-4AED intercom set suitable for a commercial building?
It is catalogued for commercial use, and the JP series capacity reflects that: 4 door stations and 7 sub-masters off one master. The PS-2420UL supply included with it is UL and CSA listed. Typical fits are a small office suite, a clinic reception, or a multi-family entry where one screen covers front and rear doors.
9) Will the Aiphone JP-DA door station see a visitor at night?
The JP-DA carries a white illumination LED for low light conditions, along with an illuminated call button so the visitor can find the button in the dark. In a fully unlit entry the LED is doing the work, so keep the station within a few feet of where a person will stand rather than set back behind a deep recess.
