Aiphone Aiphone LE-SS-1G - 1-Gang Door Station, Vandal and Weather Resistant Stainless Steel LE-SS-1G

Aiphone LE-SS-1G - 1-Gang Door Station, Vandal and Weather Resistant Stainless Steel

(No reviews yet) Write a Review

Model: LE-SS-1G

In Stock (leaves warehouse same day if ordered before 3pm ET)

$276.00
$208.84
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

The LE-SS-1G is a 1-gang stainless steel vandal proof and weather resistant sub station designed for use with the LEM, LEF, LAF/LDF-C, AP-M, and MP-S systems. This unit is constructed with 12 gauge stainless steel and can be flush mounted into a 1-gang box, or surface mounted with the SBX-SS-1G. Each unit includes tamper proof screws and a tool for installation.

FEATURES

  • Provides communication and call-in
  • Stainless steel panel
  • Weather and Vandal Resistant
  • Moisture and puncture resistant speaker
  • Hands-free communication when master answers
SPECIFICATIONS
  • Type of communication: Open voice hands-free communication
  • Mounting: Mounts flush in wall with 1-gang box/ring or directly on wall with SBX-1G
  • Wire Type: 3 cond., overall shield - use Aiphone #822203(22AWG) or #821803(18AWG)
  • Wire Distance: Door Station to farthest Master Station: 650'(22AWG) 1,600(18AWG)
  • Temperature Rating: -40° ~ 1850F (-40°~85°C)
  • Dimensions: 4-1/2" H x 2-3/4" W x 2" D

Product Specs

Product Type:
Door Stations
Series:
LEF Series
Product Group:
Electronic Access Controls
Product Subgroup:
Parts and Accessories
Subcategory:
Audio Intercoms
Commercial/Residential:
Commercial
Electronic:
Yes
Product Category:
Electronic Access Controls
Department:
Door Hardware

Aiphone LE-SS-1G – Frequently Asked Questions

1) Will the Aiphone LE-SS-1G door station work with my LEF master station?
Yes. The LE-SS-1G sub station is built for the LEM, LEF, LAF/LDF-C, AP-M, and MP-S systems, so it drops onto an existing LEF audio intercom without a separate interface. It provides call-in and open voice hands-free talk once the master answers.
2) Can the Aiphone LE-SS-1G be surface mounted, or does it need a box in the wall?
Either way. It mounts flush into a standard 1-gang box or ring, and for a wall where you cannot cut in a box, it mounts on the surface with the Aiphone SBX-SS-1G back box. Overall size is 4-1/2 inches by 2-3/4 inches by 2 inches, so plan the surface box location around that footprint.
3) How far can I run wire from an Aiphone LE-SS-1G door station back to the master?
Run distance depends on gauge: 650 feet on 22 AWG and 1,600 feet on 18 AWG, measured from the door station to the farthest master station. Wire must be 3 conductor with an overall shield, such as Aiphone 822203 (22 AWG) or 821803 (18 AWG). On a long parking-lot or gate run, pull the 18 AWG rather than trying to stretch 22.
4) Is the Aiphone LE-SS-1G rated for an exterior door in a cold climate?
It runs from -40 to 85 degrees C (-40 F), so unheated exterior entries, loading docks and gate posts are within its range. The panel is 12 gauge stainless steel and the speaker is moisture and puncture resistant, which is what makes it weather and vandal resistant rather than just an indoor station in a metal face.
5) Do I need to order tamper proof screws separately for the Aiphone LE-SS-1G?
No. Each LE-SS-1G ships with its tamper proof screws and the driver tool to install them. What you do have to add is the wire (3 conductor shielded, Aiphone 822203 or 821803), the 1-gang box or ring for flush work, or the SBX-SS-1G if you are surface mounting.
6) Is the Aiphone LE-SS-1G a video door station or audio only?
Audio only. It is a call-in and talk sub station for Aiphone's LEF-family audio intercoms, with open voice hands-free conversation once the master picks up. If a tenant needs to see who is at the door, this is the wrong part and you want a video door station instead.
7) Is the Aiphone LE-SS-1G suitable for a commercial building entrance or is it a residential unit?
It is specified as commercial. The 12 gauge stainless face and tamper proof fasteners are aimed at public entries, apartment lobbies, schools and industrial doors where the station takes abuse. Property managers standardizing an apartment or office fleet on the LEF platform can use the same 1-gang station at every opening.
