Burndy BIBD2508 8-Port Aluminum Multi-Tap Connector, Clear Insulated, 2-Sided Entry
The Burndy BIBD2508 is an 8-port aluminum Multi-Tap connector featuring clear Plastisol-covered insulation and two-sided entry for fast, flexible tap connections. Rated Al/Cu and accepting conductors from #10 AWG up to 250 kcmil, this UNITAP™ connector is designed for reliable power distribution in commercial and industrial electrical systems. A pre-installed oxide inhibitor helps protect aluminum and copper conductors from corrosion at the connection point, and the connector carries a 600V rating along with UL Listed and CSA Certified recognition.
Key Features
- Conductor Range: Accommodates #10 AWG-250 kcmil conductors, Al/Cu rated for mixed aluminum and copper installations.
- Durable Construction: Aluminum body with unplated hardware for dependable, code-compliant tap connections.
- 8-Port, 2-Sided Entry: Multi Tap connector configuration with 8 ports and double-sided entry for flexible run/tap wiring.
- Clear Insulation: Clear Plastisol-covered housing insulates the tap while allowing visual inspection of the connection.
- Voltage Rating: 600V rated for use in standard commercial and industrial power distribution circuits.
- Oxide Inhibitor: Pre-installed oxide inhibitor compound protects Al/Cu connections from corrosion and resistance buildup.
- Hardware: 8 screws with a 5/16" hex key size for secure, serviceable terminations.
Certifications & Compliance
- UL Listed
- CSA Certified
- Complies with UL468A-468B
- RoHS Compliant
Technical Specifications
- Ports: 8
- Product Material: Aluminum
- Insulated: Yes
- Industry Standards: UL468A-468B
- Min Voltage Rating: 600
- Width (in): 2.64
- Type of Hardware: Aluminum
- ROHS Compatible: Compliant
- Hex Size (Key): 5/16
- Aluminum Size (Range): 8 AWG-250 kcmil
- Type of Plating: Unplated
- Number of Screws: 8
- Height (in): 2.13
- Length (in): 7.66
- UPC: 781810224069
- UL Listed: Y
- CSA Certified: Y
- Connector Type: Multi Tap
- Conductor - AL Str Size Range: 8 AWG-250 kcmil
- Conductor - Copper Str Size Range: 10 AWG - 250 kcmil
- Product Type: Run/Tap
- Trade Name: UNITAP™
Typical Applications
- Commercial and Industrial Power Distribution
- Electrical Panelboards and Switchgear
- Run/Tap Splicing and Feeder Applications
- Al/Cu Conductor Terminations
- New Construction and Electrical Renovation
Why Burndy?
Burndy is a trusted name in electrical connectors, and the BIBD2508 UNITAP™ Multi-Tap connector reflects that reputation with UL Listed, CSA Certified construction built to UL468A-468B standards. Its aluminum body, pre-installed oxide inhibitor, and RoHS-compliant materials make it a dependable choice for professional Al/Cu tap connections.
Manufacturer Resources
Spec Sheet
Product Specs
- Wire Size:
- 10 AWG
- Ports:
- 8
- Insulated:
- Yes
- Copper Stranded (Range):
- 10 AWG-250 kcmil
- Rated for Direct Burial:
- N
- Industry Standard(s):
- UL468A-468B
- Min Voltage Rating:
- 600
- Width (in):
- 2.64
- Type Of Hardware:
- Aluminum
- ROHS Compatible:
- Compliant
- Hex Size (Key):
- 5/16
- Aluminum Size (Range):
- 8 AWG-250 kcmil
- Insulation Type:
- Plastisol
- Type of Plating:
- Unplated
- CULUS:
- N
- Ul Recognized:
- N
- Plated (Yes or No):
- N
- Number of Ports:
- 8
- Number of Screws:
- 8
- Height (in):
- 2.13
- Length (in):
- 7.66
- UPC:
- 781810224069
- UL Listed:
- Y
- CSA Certified:
- Y
- Connector Type:
- Multi Tap
- Conductor - AL Str Size Range:
- 8 AWG-250 kcmil
- Conductor - Copper Str Size Range:
- 10 AWG - 250 kcmil
- Product Type:
- Run/Tap
- Trade Name:
- UNITAP™
- Product Material:
- Aluminum
- list_batch:
- BUR-20260916
- Department:
- Electrical
- Product Subgroup:
- Lugs & Terminals
- Product Group:
- Wire Connectors & Terminals
Burndy BIBS2/05 – Frequently Asked Questions
1) Can the Burndy BIBD2508 UNITAP connector be used with both aluminum and copper conductors?
Yes. The BIBD2508 is an Al/Cu rated multi-tap connector, so you can land aluminum and copper in the same block. Aluminum stranded range is 8 AWG to 250 kcmil and copper stranded is 10 AWG to 250 kcmil. A pre-installed oxide inhibitor is already in the ports, which is what keeps an aluminum termination from building resistance, so you do not need to add compound yourself.
2) Will a 300 or 350 kcmil feeder fit the BIBD2508, or do I need a different Burndy UNITAP?
No, the BIBD2508 tops out at 250 kcmil. For larger feeders, the Burndy BIBD3508 is the same 8-port UNITAP body with a 10 AWG to 350 kcmil range. If your largest conductor is 2/0 AWG or smaller, the 6-port BIBD2/06 covers 14 to 2/0 AWG and takes up less room in the enclosure.
3) Can I use the BIBD2508 multi-tap block in a direct burial or underground handhole?
No. The BIBD2508 is not rated for direct burial. Use it inside enclosures, panelboards, switchgear and wireways only. For a buried or submerged splice you need a connector specifically listed for direct burial.
4) Can I run smaller branch taps like #10 or #8 out of the same UNITAP block as my large feeder?
Yes, that is what the block is for. Copper taps as small as 10 AWG and aluminum as small as 8 AWG land in the same ports that accept up to 250 kcmil, so one 8-port block can break a single feeder into several smaller circuits. Each port has its own setscrew, so ports can be sized independently.
5) What is the difference between a 2-sided entry and a 1-sided entry UNITAP block?
Two-sided entry means the ports are split across both faces of the block, so the run can come in one side and the taps leave the other. That suits a feeder tap in a gutter or panel where conductors approach from opposite directions. The BIBD2508 is the 8-port two-sided version. If all your conductors come from one direction, the BIBS2/05 is a 5-port one-sided entry block rated 14 to 2/0 AWG.
6) What size hex key do I need to torque the screws on the Burndy BIBD2508?
A 5/16 inch hex key drives all eight setscrews. There are 8 screws total, one per port, and the hardware is aluminum and unplated. Keep the 5/16 allen on the truck if you plan to re-torque the connections during maintenance.
7) How much room does the Burndy BIBD2508 take up inside a panel or wireway?
The block measures 7.66 x 2.64 x 2.13 inches (length x width x height). That is the connector body alone, so allow bending space for 250 kcmil conductors on top of it when you lay out a gutter or panelboard tap.
8) Is the Burndy BIBD2508 insulated, and is the insulation rated 600V?
The BIBD2508 comes with a clear Plastisol insulating cover and carries a 600V rating, which covers normal commercial and industrial distribution circuits. Because the cover is clear you can eyeball the conductor seating and the connection without stripping the block down.
9) Does the Burndy BIBD2508 meet inspection requirements for a feeder tap?
It is UL Listed and CSA Certified, built to UL468A-468B for wire connectors, and RoHS compliant. That is the paperwork an inspector or spec-driven institutional buyer normally wants on a 600V Al/Cu tap block.
10) Where can I get the manufacturer spec sheet for the Burndy BIBD2508?
Burndy publishes a spec sheet for the BIBD2508 at hubbellcdn.com/specsheet/BRDY-BIBD2508-SPEC-EN.pdf. That is the document to attach when a submittal package asks for cut sheets on the tap connectors.
