OATEY 12974 1.5 in. – 3 in. Aluminum All-Flash® No-Calk 18 in. x 18 in. Base Roof Flashing

OATEY 12974 1.5 in. – 3 in. Aluminum All-Flash® No-Calk 18 in. x 18 in. Base Roof Flashing

(No reviews yet) Write a Review

Model: 12974
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$87.14
$37.14
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
1.5 in. – 3 in. Aluminum All-Flash® No-Calk 18 in. x 18 in. Base Roof Flashing

  • Features

    • Not for hot-mopped or built-up roofs
    • For warranty product details, refer to the Oatey Limited Warranty document
    • Self-sealing collar slides over pipe and requires no caulking
    • Collar will not fade
    • Rated 180°F continuous heat and approved for Type B installations
    • Patented All-Flash® collar design allows use on multiple pipe sizes
    • Rustproof stamped aluminum base allows for easy shaping of flashing
    • Do not use petroleum based products or paint on flashing collar
    • Metal base for pitch from 0-40° or up to 10/12 roof


12974 - spec sheet

Manufacturer Resources

Product Specs

Volume:
0.153
Department:
Plumbing
Product Group:
Roofing
Product Subgroup:
Flashing and Flanges
Product Type:
Roof Flashing
Product Weight:
0.4

OATEY 12974 – Frequently Asked Questions

1) What pipe sizes does the Oatey 12974 No-Calk roof flashing fit?
The Oatey 12974 covers vent pipes from 1.5 inch through 3 inch. The patented All-Flash collar is what makes that range possible on a single part, so one flashing handles the usual mix of 1-1/2, 2 and 3 inch vent stacks on a residential roof instead of stocking three separate SKUs.
2) Do I need to caulk around the collar on the Oatey 12974 vent flashing?
No caulking. The collar is self-sealing and simply slides down over the pipe to make the seal. One caution that matters on the roof: keep petroleum based products and paint off the collar, so no roof cement smeared around the pipe and no painting it to match the shingles.
3) What roof pitch will the Oatey 12974 aluminum flashing work on?
The metal base is rated for pitches from 0 to 40 degrees, which is up to a 10/12 roof. Steeper than 10/12 and you need a flashing made for high-slope work. On the flat end it goes to 0 degrees, but read the next limitation before you use it on a low-slope roof.
4) Can I use the Oatey 12974 on a flat built-up or hot-mopped roof?
No. The 12974 is not for hot-mopped or built-up roofs. Hot asphalt application will damage it, and the collar is not compatible with petroleum based materials. For a hot-mopped commercial deck you want a flashing specified for built-up work, typically a lead or heavy galvanized base sized to the stack.
5) Can the Oatey 12974 flashing be used on a Type B gas vent?
Yes, it is approved for Type B installations and rated for 180 degrees F continuous heat. That covers Type B gas vent as well as ordinary DWV vent stacks in the 1.5 to 3 inch range. If your flue runs hotter than 180 F continuous, this is not the right base.
6) How big is the base plate on the Oatey 12974, and will it fit under a standard shingle course?
The stamped aluminum base is 18 x 18 inches, which gives you roughly the coverage a standard three-tab or architectural course expects, with the upper edge tucked under the shingles above and the lower apron lapped over the course below. Because the base is aluminum, it shapes easily to the deck instead of fighting you on an uneven roof.
7) I manage a property with several vent sizes on one roof. Can I stock one flashing for all of them?
For 1.5 inch through 3 inch vents, yes, the Oatey 12974 covers the whole range on a single part number thanks to the All-Flash collar. That works for standard shingle or shake roofs up to 10/12 pitch. Anything above 3 inch pipe, or a hot-mopped section of the building, needs a different flashing.
8) Will an aluminum roof flashing base rust out on me?
The base on the Oatey 12974 is stamped aluminum and rustproof, so it will not corrode through the way a plain steel base does. The collar is also a non-fading material, which matters on a south-facing slope where a cheap collar goes chalky in a few seasons. Aluminum is light enough to carry a stack of them up a ladder at about 0.4 lb each.
9) What is the Oatey part number for the 1.5 to 3 inch aluminum All-Flash No-Calk flashing?
Oatey 12974. That is the 1.5 to 3 inch All-Flash No-Calk unit with the 18 x 18 inch aluminum base, sold as a single-model item so there are no finish or size options to specify when you order.
