Paxton Net2 Plus, I/O Board with ABS Plastic Housing, Wall Mount, 4 Inputs, 4 Mains Rated Relay Outputs
Exit buttons may be used with compact, Switch2 or Net2 systems. They are designed to match our range of proximity readers and keypads. The exit buttons are supplied with a choice of black or white fascias which can be fitted in the final stages of installation. The E series exit buttons are available in three sizes. They are suitable for interior use. The marine exit button is designed for looks as well as function. It uses a touch sensitive lens. The Marine exit button is suitable for interior use.
Includes:
- Plastic - exit button clip on cover 75mm - Black
- Plastic - exit button clip on cover 75mm - White
- Fitting kit - E75 exit button
- Label - product serial number label 27x10mm
- Label - tech support international
- Exit Button 75mm
Specifications:
- Operating voltage: 12V DC
- Operating temperature: -20°C - 55°C
- Vandal resistance: Low
Manufacturer Resources
Product Specs
- Product Subgroup:
- Access Management
- Subcategory:
- Hardwired
- Product Group:
- Access Control
- Product Type:
- I/O Board
- Relays:
- 4
- Series:
- Net2
- Product Voltage:
- 10V - 14V DC
- Mounting Method:
- Wall
- Product Height:
- 4.3"
- Product Category:
- Access Control
- Product Width:
- 4.4"
- Department:
- Door Hardware
- Product Depth:
- 0.8
Paxton Access Inc 385-710-US – Frequently Asked Questions
1) What voltage does the Paxton Net2 Plus I/O board run on?
The Net2 Plus I/O board runs on low-voltage DC, with an operating range of 10V to 14V DC. That means a standard 12V DC access control power supply feeds it directly, and you can share the same 12V bus you are already running for readers and locks as long as it holds within that window under load.
2) How many relay outputs does the Paxton Net2 I/O board give me?
Four relay outputs. That is four independently switched circuits from one board, so a single unit can cover things like a gate, a barrier, an alarm shunt and a lighting or siren circuit off the same Net2 system rather than adding a board per output.
3) Will the Paxton Net2 I/O board fit inside my access control enclosure or does it need its own wall space?
Plan on wall mounting. The board is supplied in its own housing and measures 4.3 x 4.4 x 0.8 inches, so it takes a small footprint on a backboard or plant room wall next to the controller. The 0.8 inch depth is shallow enough to sit under most enclosure lids if you are grouping it with other Net2 gear, but the mounting method it is built for is wall.
4) Is the Paxton Net2 I/O board wired or wireless?
Hardwired. It cables back to the Net2 system rather than joining over RF, so budget for the run when you site it. That also means the four relay circuits and the board's own 10V to 14V DC supply all terminate at the board itself.
5) What color is the Paxton Net2 I/O board housing?
White. It is the only finish the board ships in, which matters if it is going somewhere visible rather than in a riser or comms cupboard.
