Record USA Slim Low Energy Auto Operator with Push & Pull Arms, 1-7/8in H x 3in D x 39.5in L, Includes Power Adaptor Plug-in Cables 120VAC

Record USA Slim Low Energy Auto Operator with Push & Pull Arms, 1-7/8in H x 3in D x 39.5in L, Includes Power Adaptor Plug-in Cables 120VAC

(No reviews yet) Write a Review

Model: HA7-100
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$3,769.00
$1,766.67
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Record USA Slim Low Energy Auto Operator with Push & Pull Arms, 1-7/8in H x 3in D x 39.5in L, Includes Power Adaptor Plug-in Cables 120VAC

The Record HA7 transforms virtually any interior door from manual to modern. Due to its smaller size profile, the HA7 has the ability to fit within tighter door frame spaces, expanding potential applications. The HA7 is easy to install, with the option of simply plugging into a standard 120-vac wall outlet. The app (available on both Google Play and Apple stores) walks you through the setup process and also serves as a useful tool for hands-free control. Close, open, hold, lock and much more with the touch of a finger. Available in clear or dark bronze anodized finishes, the HA7 requires less energy and is an eco-friendly option for single doorways while still meeting functional requirements.

Features:

  • Non-handed
  • Electrician not required with option of simply plugging into a standard 120vac wall outlet
  • Power assist
  • Push and Go
  • Parking (multiple-point hold open)
  • Privacy function (patent pending)
  • Ratchet function
  • Electric-strike integration (no external relays required)
  • UL325/UL10C certified
  • For use on single interior doors



Specifications:

  • Header Size: Height: 1.875”, Depth: 3”, Length: 39.5”
  • Power Supply: 120 VAC +10/-15%, 50/60 Hz
  • Power Consumption: Max 90 W
  • Auxiliary Voltage: 24 V DC, max 400 mA
  • Electromechanical locking connection: 12 V DC, max 1200 mA or 24 V DC, max 600 MA
  • Ambient Temperature: -20° C to +45° C
  • Relative Humidity: Max 95%
  • Door Weight (max): 200 lbs
  • Door Width (max): 48”
  • Door Opening Angle (Push): 80°-110°, with reveal 0-5 1/8”
  • Door Opening Angle (Pull): 80°-110°, with reveal 0-2”
  • Opening Time: Variable between 4.5-12 seconds
  • Closing Time: Variable between 4.5-12 seconds

Manufacturer Resources

Product Specs

Traffic Rating:
Moderate Traffic
Product Group:
Door Controls
Product Subgroup:
Automatic Operators
Product Type:
Automatic Operators
Subcategory:
Door Closers
Commercial/Residential:
Commercial
Door Hand Direction:
Non-Handed
Product Category:
Door Controls
Department:
Door Hardware

Record-USA HA7-100 – Frequently Asked Questions

1) What is the maximum door size and weight the Record USA HA7 low energy operator can handle?
The HA7 operator handles single interior doors up to 48 inches wide and 200 lbs. Past either of those numbers it is the wrong operator. It is built for single interior doors only, so an exterior entrance or a pair of doors needs a different unit. Traffic rating is moderate, so it suits an office suite, a restroom, or a unit door rather than a main entrance cycling all day.
2) Do I need to hire an electrician to install a Record HA7 door operator?
No. The HA7 ships with a power adaptor and plug-in cables and runs off a standard 120 VAC wall outlet, so a hard-wired connection is optional rather than required. That is the difference for a property manager adding an accessible door to an existing suite: no conduit, no panel work, no electrician trip charge. Supply spec is 120 VAC +10/-15 percent, 50/60 Hz, drawing a maximum of 90 W.
3) Does the Record HA7 operator have to be ordered handed, left or right?
Non-handed. One HA7 covers both left and right hand doors, and it ships with both push and pull arms, so the swing direction is set at install rather than at order time. For a contractor stocking several openings that means one part number instead of a handed pair.
4) Can a low energy operator be mounted on the pull side of the door, and does the reveal matter?
Both mountings are covered, and the reveal is what separates them. Push side allows 0 to 5-1/8 inches of reveal; pull side allows only 0 to 2 inches. Measure from the door face to the frame stop before you decide which arm to use, because a deep pull side reveal will put the opening outside the range. Either way the door opens 80 to 110 degrees.
5) Can I tie an electric strike or maglock into the Record HA7 without adding a relay board?
The HA7 has electric strike integration built in, no external relays required. The locking output is 12 V DC at up to 1200 mA, or 24 V DC at up to 600 mA, so size the strike or lock to one of those two. There is also a separate 24 V DC auxiliary output rated 400 mA max for accessories such as an actuator or card reader interface. For an integrator that removes a relay board and a second power supply from the bill of materials.
6) Is the Record HA7 operator UL listed for a fire rated door?
The HA7 is UL325 and UL10C certified. UL325 covers the door operator itself and UL10C is the fire door test standard, which is the pair a code official looks for on an operator going onto a rated opening. Confirm the door and frame assembly carry their own labels as well.
7) How do you adjust opening and closing speed on the Record HA7, and can you set a hold open?
Opening and closing times are each adjustable between 4.5 and 12 seconds, set through the Record app on Android or iOS rather than with screwdriver valves. The app also handles hold open, lock, and open/close commands. Parking gives multiple point hold open, so the door can be set to stand at more than one position, which is useful when a room needs the door held partway during moving or cleaning.
8) What is the difference between Push and Go and power assist on the Record HA7?
Push and Go means a manual nudge on the door triggers the operator to take over and complete the swing, so no wall actuator is needed for someone who can start the door. Power assist reduces the effort needed to move the door by hand without running a full powered cycle. The HA7 carries both, plus a ratchet function and a patent pending privacy function. For a property manager, that combination means an occupant can use the door normally and it still opens itself when pushed.
9) Can the Record HA7 operator be installed on an exterior door or an unheated space?
Rated for interior single doors only, so an exterior entrance is outside its application. Ambient range is -20 C to +45 C at up to 95 percent relative humidity, which covers an unconditioned interior corridor or a vestibule, but the interior door restriction still governs. For a storefront entrance you want a full size low energy or full power operator instead.
10) What finishes does the Record HA7 slim operator come in?
Two anodized finishes: 689 clear aluminum and 710 dark bronze. Clear aluminum matches most storefront and aluminum frame work already in the building; dark bronze matches bronze anodized frames and darker interior trim. The finish is on the header, which is the visible part of the assembly.
11) Is the Record HA7 rated for commercial use or is it a residential product?
Commercial rated, at moderate traffic. That puts it in offices, medical suites, schools, and multi-family common areas rather than on a high cycle main entry. It is a door control, an operator that powers the door open and closed, not simply a closer, though it takes the place of one on the opening.
