Schaub 414 4" Center to Center Lumiere Transitional Cabinet Pull

The 414 Lumiere pull takes 8/32 x 1 inch machine screws, the standard cabinet pull thread. A 1 inch screw covers typical 3/4 inch cabinet doors and drawer fronts with thread to spare. If you are mounting through a thicker front, a five-piece drawer front, or a face with an applied panel, you will need longer 8/32 screws, which is a stock size any hardware supplier carries.

Two direct alternatives on the same 4 inch drilling: the Omnia 1968/102, a forged solid brass modern pull with 4 inch center-to-center spacing, and the Trimco 562 Series drawer pull, which is offered in 3-1/2 inch, 4 inch, and 96mm center-to-center. The Omnia is the closer match on material, since it is forged solid brass like the Schaub. The Trimco 562 is the institutional-looking option and gives you a 96mm choice if you are matching European-drilled casework.

The Schaub 414 will not fit 3 inch holes, it is drilled on 4 inch centers and there is no adjustment. For an existing 3 inch drilling, the Trimco 553 Series drawer pull is a 3 inch center-to-center pull. If your holes measure 3-1/2 inches, the Deltana SBP35 modern square bar pull is a 3-1/2 inch solid brass option, and the Trimco 562 Series also lists a 3-1/2 inch center-to-center. Redrilling to 4 inches leaves the old holes exposed under most pull footprints, so match the existing spacing where you can.

The Omnia 1968/102 is the nearest direct equivalent. Both are solid brass cabinet pulls on 4 inch center to center spacing, so they land on the same existing drilling in a door or drawer front. The Schaub 414 Lumiere is a transitional style pull with a 6 inch overall length and 1-1/4 inch projection; the Omnia 1968/102 is a modern style forged solid brass pull. If the drilling is set and the look is open, either drops onto the same two holes.

The Schaub 414 Lumiere is fixed at 4 inch center to center, so a 3 inch drilling will not take it without new holes. The Trimco 553 Series drawer pull is a 3 inch center to center pull and lands on that existing spacing. If the fronts are mixed, the Trimco 562 Series covers 3-1/2 inch, 4 inch, and 96mm center to center, which lets one series cover both a 3-1/2 inch legacy drilling and the 4 inch drilling the Schaub 414 uses.

Not on the same holes. The Deltana SBP35 is a modern square bar pull on 3-1/2 inch spacing in heavy-duty solid brass, while the Schaub 414 Lumiere is 4 inch center to center. The materials line up - both are solid brass - but the half inch difference in spacing means the SBP35 needs its own drilling. It is worth a look on a new casework package where the holes are not yet bored and a square bar profile suits the room; it is not a like-for-like swap on cabinets already drilled for the 414.

Only where you are willing to change the drilling. The Orca Hardware CK-15030 and CK-16030 Bachelor Collection are round cabinet knobs at 1-1/4 inch diameter, and the CK-17025 Blackcomb is a square knob at 25mm - all single-hole knobs. The Schaub 414 Lumiere is a two-hole cabinet pull on 4 inch centers with a 6 inch overall length. A knob will not cover the two existing bores, so swapping a pull for a knob means new fronts or filled and refinished holes. Knobs are the right call on small doors and narrow stiles where a 6 inch pull will not fit; they are not a drop-in for the 414.

Six finishes: Polished Brass (PB), Satin Brass (SB), Polished Nickel (PN), Satin Nickel (SN), Polished Chrome (PC), and Polished Rose Gold (PRG). That is a two-per-family spread, brass, nickel, and a chrome plus rose gold, so if you are matching existing cabinet hardware or a faucet finish in a kitchen or bath package, work from the suffix code on what is already installed rather than the finish name, since names vary between manufacturers and the code does not.

Solid brass is the base material, not zinc or plated die cast. For multi-family, hospitality, or any property manager buying for a whole building, that is the difference that decides service life on cabinets that get pulled dozens of times a day. It also means the finish is applied over brass, so wear at the grip points shows warm brass rather than a bright white base metal.

A pull like the Schaub 414 spans 4 inch centers and gives a full-hand grip standing 1-1/4 inches off the face, which is what you want on drawers, heavy doors, and anywhere hands are wet or gloved. A knob is a single-hole mount and suits small doors and light drawers. If you want knobs on the doors and pulls on the drawers, the Orca Hardware Bachelor Collection round knob at 1-1/4 inch diameter and the Blackcomb Collection square knob at 25mm diameter are knob options.

Six finishes on a single 4 inch drilling makes this workable as a fleet standard: Polished Brass, Satin Brass, Polished Nickel, Satin Nickel, Polished Chrome, and Polished Rose Gold. Because the center-to-center never changes across the finishes, your casework drilling stays identical building-wide and only the finish code changes per unit tier or per renovation phase. Order by finish suffix, PB, SB, PN, SN, PC, or PRG, so the drilling spec on the shop drawings stays one line.

The Omnia 1970 is a forged solid brass modern cabinet pull with a 1-1/4 inch projection, the same standoff from the face as the Schaub 414 Lumiere. Projection is what decides finger clearance and whether a pull clears an adjacent appliance handle or a door swing in a tight galley run, so on a kitchen or casework package where that dimension was set by the drawing, the Omnia 1970 holds it. The Omnia 1969 and Omnia 1971 both sit at 1-3/16 inch projection, a sixteenth shallower.

The Orca Hardware CK-12001 T-Pull Bar is a steel pull with a 2 inch bar width in satin nickel, a plainer bar profile than the transitional Schaub 414 Lumiere in solid brass. For property managers standardizing a large unit count on utility cabinetry, a single steel bar pull in one finish keeps the fleet consistent and the spec short. Keep the 414 Lumiere where the solid brass body and its six finishes - polished brass, satin nickel, polished chrome, polished nickel, polished rose gold, and satin brass - need to carry a designed room.

The Schaub 414 Lumiere uses 8/32 x 1 inch machine screws, the standard cabinet pull thread, and that screw size is part of the pull's own specification. Do not confuse it with a door hardware spindle such as the SDC SP50 50mm spindle, which is a door controls part and has nothing to do with mounting a cabinet pull. For fronts thicker than standard, order longer 8/32 screws to suit.
