Schlage L9010 - Passage Latch ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$1,132.00
$792.40
Schlage L9010 Passage Latch Mortise Set – exploded view showing mortise lock body with lever and escutcheon in satin chrome finish

Schlage L9010 - Passage Latch Mortise Set

(4 reviews) Write a Review
New Parts & Accessories Available!

Model: L9010 06A 626
From the L9000 Series Collection
$1,132.00
$792.40
Selected Lever Style is
Selected Finish is
Selected Rose/Escutcheon Design is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,132.00
$792.40
Adding to cart… The item has been added
New Parts & Accessories
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Default Attributes
Style: Same lever, rose and finish for both sides of the door with coordinating latch and strike.
Latch: ANSI/BHMA Certified A156.13-2012, Series 1000, Grade 1 Operational,
Grade 1 Security, UL Listed for 3-hour fire door (except L9076 and L9077).
With FSIC Interchangeable Core Cylinders: Grade 1 Operational, Grade 2 Security.
With SFIC Interchangeable Core Cylinders: Grade 1 Operational, Grade 3 Security.
Case Size: 4-7/16" x 6-1/16" x 1";
Armor Front: 1-1/4" x 8";
Deadbolt: 1" Throw stainless steel;
Latchbolt: 3/4" Throw stainless steel with anti-friction tongue;
Strike: 1-1/4" x 4-7/8" Square corner, 1-3/16" lip, box;
Backset: 2-3/4";
Door Thickness: 1-3/4".



Schlage L9010 PASSAGE SET

  • Latchbolt retracted by lever/knob from either side at all times;
  • Inside lever always free for immediate egress.



Schlage L SERIES OVERVIEW

The Schlage L Series has long been the benchmark for mortise locks. The L Series is more than strength and security – it offers tremendous flexibility to allow it to meet the needs of most every application. Over 55 functions, 35 lever and knob designs, eight different roses and escutcheons, and a multitude of prep options are just the beginning.

180 degree visibility indicators, advanced motor-driven electrified functions, a universal lock case that supports 10 different functions, and the ability to suite across tubular, exit device, and multipoint locks allow the Schlage L Series to integrate seamlessly into any environment.



FEATURES & BENEFITS

Security

  • Exceeds ANSI/BHMA Grade 1 Security and Operational standards
  • Deadbolt functions include anti-saw pin in bolt to prevent cut-through
  • Security blocking hub prevents lock picking by removing levers



Function availability and compatibility

  • 55+ standard functions (custom functions are also available)
  • Universal lock case allows 10 functions to be created from a single lock body
  • Electrified locks auto detect 12V/24V DC, have customer-selectable EL/EU, and offer advanced features like: RX, DPS, latchbolt monitor and deadbolt monitor for application flexibility while offering leading energy efficiency



Aesthetics

  • 14 finishes
  • 33 lever, two knob, five rose and three escutcheon designs
  • Locking lever bushing eliminates exposed screws on inside levers
  • All levers suite with Von Duprin exit devices, along with related L Series products LE, LM9200, LM9300 and LT



Options

  • Exclusive 180° visibility indicator
  • Vandlgard® free-wheeling outside trim option is available on most functions, including electrified
  • Expansive options portfolio, including different door thickness, finish/trim combinations, tactile warning, anti-microbial coatings, etc.
  • New Gold Standard ligature resistant trim for behavioral health applications



AVAILABLE L SERIES FUNCTIONS

View the Schlage L Series catalog for descriptions of all available functions.



CERTIFICATIONS & TESTING

View the Schlage L Series catalog to see all specifications and certifications.

Certifications

  • Meets BAA (Buy American Act)
  • L9000: tested and certified under ANSI/BHMA A156.13, Grade 1 Security and Operational
  • UL listed for 3-hour fire door (except L9076 and L9077)
  • With interchangeable core cylinders: Grade 2 security
  • With concealed shell cylinder: A156.13 Grade 1 operational and security
  • ANSI/ASTM F476-76 Grade 40, UL listed
  • L400: tested and certified under ANSI/BHMA A156.36 Grade 1
  • California Referenced Standards Code: all levers with a return to door of 1/2" (64 mm) or less comply
  • UL/cUL listed for A label single doors, 4' x 10' and pairs 8' x 10'; letter F and UL symbol on latch front indicate listing
  • Electrified functions are UL19X listed for single-point locking applications
  • UL437 listed locking cylinder optional: specify Primus 20-500 Series cylinder
  • Miami-Dade NOA's and Florida Building Commission Listings
  • Meet ADA requirements



DOWNLOADS & RESOURCES



Technical resources



Manufacturer Resources

Product Specs

Subcategory:
Mortise Locks
Product Group:
Mechanical Locks
Series:
L Series
Function Description:
Latchbolt retracted by knob/lever from either side at all times. Inside lever is always free for immediate egress.
Grade:
Grade 1
Duty Level:
Heavy Duty
Keyed Function:
Non-Keyed
Handle Type:
Lever
Standard Latch:
3/4" Stainless Steel Latch with Anti-Friction Tongue
Standard Strike:
10-072 1-1/4" x 4-7/8" Square Corner Strike, Box (1-3/16" Lip Length)
Mortise Case Size:
4-7/16" x 3-5/8" x 1"
Warranty:
3 Year Limited
Keyed:
No
ANSI/BHMA:
ANSI/BHMA A156.13 Grade 1
Product Subgroup:
Mortise Locks and Trim
Product Type:
Mortise Locks
Commercial/Residential:
Commercial
Lock Type:
Mortise
Lock Function:
Passage
IMAP Policy:
Yes
Product Attribute:
Mortise Locks
Electronic:
No
Tags:
l9010 06a, schlage 9010, schlage l9010 06a, l9010 schlage
Product Model:
L9010
Collection:
L9000 Series
Product Function:
Passage/Hall/Closet
Door Hand Direction:
Field Reversible
Door Thickness Range:
1-3/4" standard (optional preps available for other thicknesses)
Product Category:
Mechanical Locks
Product Substrate:
CRS with Zinc Dichromate Plating
Backset (Distance):
2-3/4"
Department:
Door Hardware

Parts & Accessories

    Schlage L9010 06A 626 – Frequently Asked Questions

    1) What is the 2-3/4 inch backset on the Schlage L9010 and will it match my existing mortise prep?
    The L9010 uses a 2-3/4 inch backset, which is the standard commercial mortise backset, so it drops into a door already prepped for an ANSI mortise lock of that dimension. Measure from the door edge to the centerline of the lever spindle on the old lock to confirm. If your existing prep is a 2-1/2 inch backset, as on the Baldwin 6301 mortise lock body, the L9010 will not line up.
    2) Does the Schlage L9010 lock the door at all, or is it just a latch?
    It never locks. The L9010 is a passage function: the latchbolt retracts from the lever on either side at all times, and the inside lever is always free for egress. There is no cylinder and no keyway, since it is a non-keyed lock. Use it on corridor doors, hall doors, and closets where you want a Grade 1 mortise lever but no security. If you need the door to lock, look at a keyed L Series function instead.
    3) Will the Schlage L9010 latch into the strike that is already in my frame?
    The latchbolt is a 3/4 inch throw stainless steel bolt with an anti-friction tongue, and the lock ships with the Schlage 10-072 box strike, 1-1/4 x 4-7/8 inches, square corner, with a 1-3/16 inch lip. If your frame already has a square-corner ANSI strike cut of that size, the new latch will engage it. If your existing strike is radius corner or a different height, install the supplied strike and adjust the frame cutout. The 1-3/16 inch lip length is set for a standard frame reveal; a deeper reveal wants a longer lip.
    4) Is the Schlage L9010 handed, or can I use one lock on both left and right hand doors?
    No handing to specify on the lock itself. The L9010 is field reversible, so one lock serves either hand and you can stock a single part across a building. The one place hand does matter is trim selection: the 12 lever design is ordered as either left hand or right hand, while the 01, 02, 03, 05, 06, 07, 17, 18, Latitude, Longitude and Omega designs are not handed.
    5) Can I use the Schlage L9010 on a 3 hour fire rated door?
    Yes. The L9000 latch is UL listed for 3-hour fire doors, and the UL/cUL listing covers A label single doors up to 4 by 10 feet and pairs up to 8 by 10 feet. The letter F and the UL symbol stamped on the latch front are how the inspector verifies it in the field. Since passage function leaves the door unlocked at all times, egress is never impeded.
    6) What is the closest equivalent to a Schlage L9010 passage mortise lock from another manufacturer?
    The Falcon MA101 is the nearest match. Like the L9010, it is a Grade 1 heavy duty mortise lock built for the passage/hall/closet function, and it is field reversible, as the L9010 is. Both leave the latchbolt retracted by the lever from either side at all times, so neither one locks. The MA101 is fire rated. If the specification calls for a non-keyed Grade 1 mortise passage latch and the L9010 lever and escutcheon designs are not required, the MA101 covers the same opening.
    7) What is a Grade 1 passage mortise lock alternative with an escutcheon instead of a rose?
    The Hager 3810E is a Grade 1 passage mortise lock supplied with an escutcheon and a 2-3/4 inch backset, matching the 2-3/4 inch backset of the Schlage L9010. Its companion, the Hager 3810S, is the same passage function with a rose instead. The Hager 3800 Series passage locks carry a door thickness range of 1-3/4 inch to 2-1/2 inch, while the L9010 is built around 1-3/4 inch doors as standard with optional preps for other thicknesses. The L9010 itself is ordered with either a wrought rose, a full face escutcheon, or an escutcheon, so both trim styles are reachable within the L Series as well.
    8) The opening needs to lock. What mortise lock should be used instead of an L9010 passage set?
    The L9010 is non-keyed and does not lock at all - the latchbolt is retracted by the lever from either side at all times. For a keyed opening, the Accentra 8805FL is a Grade 1 storeroom mortise lock in the 8800 Series, and the Cal-Royal NM8080 is a Grade 1 storeroom mortise lockset for 1-3/4 inch doors with an interchangeable core option. For an office opening, the Cal-Royal NM8050 is a Grade 1 entrance/office mortise lockset for 1-3/4 inch doors with an auxiliary deadlatch. Within the L Series, the same lock case supports keyed functions under different L9000 model numbers.
    9) What replaces a passage mortise lock on a restroom or bedroom door that needs privacy?
    A passage set such as the Schlage L9010 has no locking at all, so it is wrong for a restroom or bedroom. The Cal-Royal NM8440 is a Grade 1 privacy mortise lockset with a deadbolt for 1-3/4 inch doors, and the Hager 3840S is a Grade 1 privacy mortise lock with a 2-3/4 inch backset, the same backset the L9010 uses, on doors 1-3/4 inch to 2 inch. Either keeps the same mortise pocket approach while adding the privacy function the opening requires.
    10) What passage mortise lockset should be used for a behavioral health or patient room instead of a standard lever set?
    For anti-ligature openings, the TownSteel MRX-L-01 is a Grade 1 heavy duty stainless steel anti-ligature lever mortise lockset in the passage/hall/closet function for 1-3/4 inch doors, and the MRX-A-01 is the same passage function with satin stainless ligature resistant arch trim. Where a push/pull is wanted rather than a lever, the Marks USA 5PDN is a Grade 1 hospital passage mortise push/pull paddleset, ligature resistant and ADA compliant in satin stainless steel. All three hold the same passage behavior as the Schlage L9010, which is offered with lever trim.
    11) What do I have to specify when ordering a Schlage L9010 mortise passage set?
    Three choices beyond the function. Lever design: 01, 02, 03, 05, 06, 07, 12 (left or right hand), 17, 18, Latitude, Longitude or Omega. Rose or escutcheon: A wrought rose, B wrought rose, L full face escutcheon, or N escutcheon. Finish: 605 bright brass, 606 satin brass, 609 antique brass, 612 satin bronze, 613 oil rubbed bronze, 619 satin nickel, 622 matte black, 625 bright chrome, 626 satin chrome, 630 satin stainless, or 643E aged bronze. Both sides of the door get the same lever, rose and finish, with the matching latch and strike.
    12) Is the Schlage L9010 ADA compliant for a lever on a public corridor?
    It meets ADA requirements, and because passage function needs no tight grasping or key operation the lever is operable with a closed fist. On the code side, all L Series levers with a return to door of 1/2 inch (64 mm) or less comply with the California Referenced Standards Code, so check the specific lever design against that if you are building in California.
    13) How does the Schlage L9010 compare to other Grade 1 mortise passage locks?
    Closest equivalents ZenSupply carries are the Falcon MA101, a Grade 1 heavy duty mortise passage lock that is also field reversible and fire rated, and the Hager 3810S (rose) or 3810E (escutcheon), Grade 1 passage locks on the same 2-3/4 inch backset that cover a 1-3/4 to 2-1/2 inch door thickness range out of the box. For behavioral health or detention openings where the lever has to be ligature resistant, the TownSteel MRX-L-01 lever or MRX-A-01 arch trim covers the same passage function in Grade 1 stainless. The L9010's argument is the trim depth: 13 lever designs and 4 rose or escutcheon options so it matches the rest of an L Series building.
    14) Will the Schlage L9010 levers match the exit devices and other locks already in my building?
    They will. All L Series levers suite with Von Duprin exit devices and with the related L Series products LE, LM9200, LM9300 and LT, so a passage opening, a keyed opening and a device opening can carry the same lever design and finish. Pick one lever style and one finish from the 11 offered and hold it as the building standard.
    15) Is the Schlage L9010 heavy enough for a high traffic school or hospital corridor?
    It is a heavy duty commercial lock, certified under ANSI/BHMA A156.13 Grade 1 for both operational and security, which is the top tier for mortise locks and the usual institutional spec. The case is cold rolled steel with zinc dichromate plating and the latchbolt is stainless steel. Passage function has no cylinder to wear, so the cycle life is in the lever and hub.
    16) Can I put an electric strike or access control on a Schlage L9010 opening?
    The L9010 itself is a mechanical, non-electronic lock, so there is no wiring to it. If the opening needs credential control, that means a different product rather than an accessory: the L Series carries electrified functions that auto detect 12V or 24V DC with selectable EL/EU and options like RX, DPS and latchbolt monitoring, and ZenSupply also stocks the Schlage Electronics LEMD Grade 1 ENGAGE wireless mortise lock with a 125kHz proximity reader and the CO-100 standalone keypad mortise lock. Passage function is for openings that are meant to stay free.
    17) Is an Emtek 3102 Memphis mortise lockset a substitute for a Schlage L9010?
    No. The Emtek 3102 Memphis, and the companion 3104 Hamilton, 3106 Manhattan, and 3019 Brisbane, are dummy function mortise entrance locksets - a dummy has no working latch and only mounts trim to the door face. The Schlage L9010 is a passage set with a 3/4 inch stainless steel latchbolt with anti-friction tongue that is retracted by the lever from either side. If the door needs to latch closed, a dummy set will not do it.
    18) What is the difference between a Schlage L9010 and a Corbin Russwin ML2003 or Cal-Royal NM8070 classroom mortise lock?
    Function. The Corbin Russwin ML2003 is a Grade 1 mortise classroom lockset in the ML2000 Series for 1-3/4 inch doors, and the Cal-Royal NM8070 is a Grade 1 classroom mortise lockset for 1-3/4 inch doors with an auxiliary deadlatch - a classroom function locks the outside lever by key. The Schlage L9010 is non-keyed: the lever retracts the latch from both sides at all times and the inside lever is always free for immediate egress. Both classroom locks are Grade 1, as the L9010 is under ANSI/BHMA A156.13.
    19) What should be specified instead of an L9010 when the opening needs credentialed or keypad access?
    The L9010 is a mechanical, non-electronic lock. For electronic access on a mortise prep, the Schlage CO-100 is a Grade 1 standalone electronic mortise lock with a keypad reader for 1-3/4 inch doors, and the Schlage LEMD-GRW is a Grade 1 ENGAGE Series wireless mortise lock with a 125kHz proximity reader, mobile enabled, with a 3 hour fire rating. The Alarm Lock DL3500CR is a Grade 1 Trilogy electronic mortise lock with 300 user codes in the classroom function for doors 1-5/8 inch to 1-7/8 inch, and the TownSteel FME-2000 is a Grade 1 heavy duty classroom mortise lockset with RFID for 1-3/4 inch doors. Each of these adds credential control the passage L9010 does not carry.
    20) Can a BEST 45H mortise lock body be used in place of a Schlage L9010?
    They are not the same order. The BEST 45H is a heavy duty mortise lock body in the public entrance function with field reversible operation, and the 45HCA is a heavy duty lockbody in the intruder function - these are lock bodies, ordered separately from trim. The Schlage L9010 is a complete passage set with the lock body, lever, rose or escutcheon, latch and strike together, and it is also field reversible. If only the case is being replaced in an existing L Series opening, the L9000 Series lock body is the matching part rather than a 45H body.
    21) Will a Baldwin 6301LS mortise lock fit the same door prep as a Schlage L9010?
    No - the backsets differ. The Baldwin 6301LS is an entrance/apartment mortise lock body with a 2-1/2 inch backset for doors 1-3/4 inch and over, and the Baldwin 6310 entrance/storeroom body is also 2-1/2 inch backset. The Schlage L9010 uses a 2-3/4 inch backset with a 4-7/16 inch x 3-5/8 inch x 1 inch case. A 2-1/2 inch backset body puts the spindle and cylinder holes in a different place on the door face, so it is not a drop-in for an L Series prep.
    22) What mortise lock is used on a glass door or a narrow aluminum stile where a Schlage L9010 will not fit?
    An L Series mortise set needs a 4-7/16 inch x 3-5/8 inch x 1 inch case pocket, which a narrow stile or a glass door rail will not take. The Kaba Ilco BR Series is a glass door bottom rail lock built for that condition. For an aluminum stile door, the Alarm Lock DL1300NW is a Trilogy Networx wireless electronic mortise lock with keypad made for Adams Rite deadlatches, and the Dormakaba E-Plex 2066 is an electronic pushbutton keyless mortise lock for wide stile doors.
    23) Should I use a mortise passage lock or a cylindrical one on a hall door?
    Mortise means a rectangular pocket routed into the door edge rather than two round bores, so the choice is usually made by the door you already have. If the leaf is prepped with an ANSI mortise pocket, the L9010 drops in on its 2-3/4 inch backset and 4-7/16 x 3-5/8 x 1 inch case. Prepping a cylindrical door for mortise is a shop operation, not a field one. What mortise buys you is the heavier case, Grade 1 operation, and the ability to swap functions later within the L Series without recutting the door.
    24) Is the Schlage L9010 Buy American Act compliant for a government job?
    It meets BAA (Buy American Act), which is what most federal and many state procurement specs require. It also carries Miami-Dade NOAs and Florida Building Commission listings if the project is in a Florida wind-borne debris region.
    25) Is a Sargent 4874 or Kaba Ilco 185 mortise deadbolt an alternative to a Schlage L9010?
    They do different jobs. The Sargent 4874 is a double cylinder mortise deadbolt with a 2-3/4 inch backset, and the Kaba Ilco 185 Series is a no-handing mortise deadbolt. A deadbolt holds the door shut but provides no lever and no latching; the Schlage L9010 is a lever-operated passage set whose 3/4 inch stainless latchbolt is retracted from either side. On an opening that needs both a latch for normal use and a bolt, a deadbolt alone is not a replacement.
    26) Is there a lighter duty mortise latch than the Schlage L9010 for a low traffic interior door?
    The Codelocks CL2255 is an electronic tubular mortise latch in the CL2000 Series rated medium duty, in a brushed steel finish. The Schlage L9010 is a heavy duty Grade 1 mortise lock certified to ANSI/BHMA A156.13, built for commercial traffic. On a low traffic interior door where a heavy duty certified mortise set is not required, the medium duty CL2255 is a lighter option, though it is a keypad latch rather than a plain lever passage set.
    27) What is the difference between a Schlage L9010 passage set and a Sargent 7925 dormitory lock?
    The Sargent 7925 is a Grade 1 heavy duty mortise lock in the 7900 Series with the corridor/dormitory exit function, rose trim and a single cylinder deadbolt. The Schlage L9010 is heavy duty and Grade 1 as well, but it is non-keyed with no deadbolt - only the 3/4 inch latchbolt, retracted by the lever from both sides. The 7925 suits a dorm or corridor opening that needs a keyed deadbolt with free egress; the L9010 suits an opening that never locks.
    How fast can I get the Schlage L9010 06A 626 delivered?
    Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
    Can I return it if it doesn’t work for me?
    Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.
    Does the Schlage L9010 06A 626 come with a warranty?
    Absolutely. The Schlage L9010 06A 626 is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.
    How do I get technical support or installation help for the Schlage L9010 06A 626?
    You can call, text, or email our expert support team for fast answers. We’re here to help with product selection, installation tips, and troubleshooting. Contact Us
    Why buy the Schlage L9010 06A 626 from ZenSupply?
    ZenSupply makes it easy to get the commercial door hardware you need—fast shipping, expert support, and rewards on every order. Our team is always ready to help you choose the right product for your project.
