WAC Lighting BA-AC18-CS-WT 18" LED Light Bar with 3-CCT Selectable and Rocker Switch

WAC Lighting BA-AC18-CS-WT 18" LED Light Bar with 3-CCT Selectable and Rocker Switch

(No reviews yet) Write a Review

Model: BA-AC18-CS-WT
From the Light Bar Collection

In Stock (leaves warehouse same day if ordered before 3pm ET)

$65.95
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

WAC Lighting BA-AC18-CS-WT 18" LED Light Bar with 3-CCT Selectable and Rocker Switch

Features

  • Delivered Lumens: Up to 1075lm
  • 2700K/3000K/3500K
  • CRI: 90
  • Power: 10.5W, 15W, 17.5W, 6.5W
  • Input: 120 VAC, 50/60Hz
  • ELV Dimming: 100-10%
  • Rated Life: 50000 Hours
  • Construction: Extruded aluminum with Acrylic Diffuser
  • 3-CCT Switchable between 2700K and 3500K
  • Does not require any driver or transformer
  • Backlighting with parabolic reflector allows a high uniformity of light
  • Minimal space between diffusers for a visually seamless line of illumination
  • True 1" profile
  • Prevents microbial growth on the surface of the fixture
  • ACLED driverless technology

Manufacturer Resources:

Specification Sheet

Installation Guide

Manufacturer Resources

Product Specs

ADA Compliant:
Yes
Bulb Base:
Integrated LED
Bulb Shape:
LED Module
Bulbs Included:
Yes
Collection:
Light Bar
Dimmable:
ELV, TRIAC
Hardwired or Portable:
Portable
Lumens:
750
Number of Bulbs:
1
Product Type:
Bar Light
Shade/Glass Description:
White Acrylic Diffuser
Warranty:
5 Years Functional, 2 Years Finish
Product Group:
Indoor Lighting
Product Subgroup:
Accessories
Avg Rated Hours:
50000
Base Material:
Extruded Aluminum
Location Rating:
Damp
Brand Family:
WAC Limited
CEC Listed:
Yes
CRI:
90
Energy Star:
No
Subcategory:
Bar Lighting
Certification:
ETL, cETL
Glass Finish:
White Acrylic Diffuser
Location Indoor/ Outdoor:
Indoor/Outdoor (Covered)
Shade Material:
Acrylic
Title 24 Compliant:
Yes
Bulb Type:
LED
Segment:
Lighting
Product Voltage:
120V
Product Length:
3.23"
Light Temperature:
2700K-3000K-3500K
Mounting Method:
Any
Product Style:
Functional
Product Height:
21.26"
Product Category:
Task & Cove
Product Width:
1.89"
Product Wattage:
10W

WAC Lighting BA-AC18-CS-WT – Frequently Asked Questions

1) Does the WAC BA-AC18 light bar need a separate LED driver or transformer?
No. The BA-AC18 runs on 120V line voltage using WAC's ACLED driverless technology, so there's no remote driver, transformer, or low-voltage run to plan for. Wire it to a standard 120 VAC, 50/60Hz circuit and it's done. That's the main reason installers pick this over a 24V tape system under cabinets or in a cove.
2) What dimmer works with the WAC BA-AC18 light bar?
Use an ELV (electronic low voltage) or TRIAC forward-phase dimmer. On ELV the bar dims from 100 percent down to 10 percent. Because it's a line-voltage driverless fixture, pair it with a dimmer rated for LED loads and confirm your total connected wattage falls within the dimmer's minimum load.
3) Can I put a WAC BA-AC18 light bar in a bathroom or a covered porch?
It carries a damp location rating, so a covered porch, soffit, or bathroom vanity area away from direct spray is fine. It is not rated for wet locations, so skip open exterior runs, uncovered patios, or anywhere it takes rain directly. Certification is ETL and cETL for US and Canadian jobs.
4) Does the WAC 18 inch light bar count toward Title 24 and ADA on a California job?
Yes on both. The BA-AC18 is listed as Title 24 compliant and CEC listed, which is what a California inspector will look for on residential and light commercial work, and it's flagged ADA compliant, useful in corridors and other spaces with protrusion limits since the housing holds a true 1 inch profile.
5) Will the WAC light bars butt together into a continuous line, or will I see dark spots between them?
They're built to run end to end with minimal space between diffusers, and the LEDs fire into a parabolic reflector rather than straight out, so the white acrylic lens reads as an even line instead of a row of dots. That backlit construction is what makes this a reasonable choice for an exposed cove or a glass shelf where the diffuser is in the sightline.
6) Is the WAC BA-AC18 durable enough for a rental kitchen or a hospitality property?
The body is extruded aluminum with an acrylic lens, and the LED module is integrated and rated for 50,000 hours, so there's no lamp for a tenant to replace or for maintenance to stock. The surface also resists microbial growth, which matters in healthcare and food-service casework. Integrated LED does mean the whole fixture is the replacement unit at end of life.
7) Do I need to hardwire the WAC BA-AC18 or can it plug in?
It's classified as portable rather than hardwired, so it's set up to connect without cutting into branch circuit wiring, and the onboard rocker switch gives you local on/off at the fixture. That makes it workable in retrofits where you don't want to open up finished casework or pull a new switch leg.
8) Can the WAC light bar be mounted vertically or upside down under a shelf?
Mounting orientation is open, any position, so undercabinet, on top of a cabinet for uplight, vertically in a pantry, or in a cove all work. Do the layout around the rocker switch and the cord entry so the switch stays reachable and the connection point lands where you can get to it.
