Modern Forms FR-W1814 Woody 3-Blade DC Ceiling Fan
The Modern Forms FR-W1814 Woody 3-Blade DC Ceiling Fan pairs a 60" span of solid balsa wood blades with a quiet reversible DC motor for rugged, refined performance indoors or outdoors. Wet Location Listed and available in bronze, matte black, or graphite housing, it integrates a replaceable LED luminaire delivering 1600 lumens and 90 CRI, syncing with the Modern Forms app for Adaptive Learning, breeze mode, and voice-assistant control.
Key Features
- Blade Configuration: 3 solid balsa wood blades, 60" span, 26" blade length, 13-degree pitch for strong, quiet airflow.
- Reversible DC Motor: Factory-balanced DC motor with 6 speeds and up to 7268 CFM airflow, up to 70% more efficient than AC fans.
- Smart App Control: Free Modern Forms app enables Adaptive Learning, breeze mode, grouping, and compatibility with Google Assistant, Amazon Alexa, SmartThings, Control4, and Josh AI.
- Integrated LED Luminaire: Replaceable LED module delivers 1600 lumens at 50.5W with 90 CRI and dimmable brightness control; concealment cover included.
- Wet Location Rated: UL, cUL, CSA, ETL, and cETL Wet Location Listed for indoor or outdoor use, including slopes up to 30 degrees.
- Downrod Mounting: Includes a 4.5" downrod; longer downrods sold separately.
Certifications & Compliance
- UL Listed
- cUL Listed
- CSA Certified
- ETL Listed
- cETL Listed
- Wet Location Listed for Indoor or Outdoor Use
- Energy Star Qualified
Technical Specifications
- ADA Compliant: No
- Bulb Base: LED Module
- Collection: Woody
- Dimmable: Yes
- Energy Star: Yes
- Lumens: 1600
- Product Type: Downrod Ceiling Fans
- Safety Rating: ETL, cETL, UL, cUL, CSA
- Warranty: 5-yr LED module, 2-yr finishes, lifetime motor, 1-yr other parts.
- Subcategory: Indoor or Outdoor Smart Home Ceiling Fan
- Avg Rated Hours: 50000
- CRI: 90
- Beam Spread: Flood
- Voltage: 120
- Country of Origin: Taiwan
- Location Rating: Wet
- Total Wattage: 50.5
- Blade Span: 60"
- Number of Blades: 3
- Blade Length: 26"
- Blade Material: Solid Balsa Wood
- Blade Pitch: 13 degrees
- Motor Type: DC
- Reversible Motor: Yes
- Fan Speeds: 6
- Airflow CFM: 7268
- Remote Included: Yes
- Wall Control Included: No
- Downrod Length: 4.5"
Typical Applications
- Covered Outdoor Patios and Porches
- Indoor Great Rooms and Living Areas
- Smart Home Integrated Installations
- Sloped Ceiling Installations to 30 Degrees
- Wet-Location Residential Spaces
Why Modern Forms?
Modern Forms builds the Woody collection around a factory-balanced, sound-tested DC motor and solid balsa wood blades, backed by UL, cUL, CSA, ETL, and cETL Wet Location Listing for confident indoor or outdoor use. With a 5-year LED module warranty and lifetime motor warranty, it's engineered for lasting, code-compliant performance.
Manufacturer Resources
Specification Sheet
Product Specs
- ADA Compliant:
- No
- Bulb Base:
- LED Module
- Collection:
- Woody
- Dimmable:
- Yes
- Energy Star:
- Yes
- Lumens:
- 1600
- Product Type:
- Downrod Ceiling Fans
- Safety Rating:
- ETL, cETL, UL, cUL, CSA
- Warranty:
- 5 years LED module, 2-years for finishes, lifetime on the motor, 1 year for all other parts.
- Subcategory:
- Indoor or Outdoor Smart Home Ceiling Fan
- Avg Rated Hours:
- 50000
- CRI:
- 90
- Beam Spread:
- Flood
- Voltage:
- 120
- Country of Origin:
- Taiwan
- Location Rating:
- Wet
- Total Wattage:
- 50.5
- Style:
- Traditional
- Blade Span:
- 60"
- Number of Blades:
- 3
- Blade Length:
- 26"
- Blade Material:
- Solid Balsa Wood
- Blade Finish:
- Dark Walnut
- Blade Pitch:
- 13 degrees
- Motor Type:
- DC
- Reversible Motor:
- Yes
- Fan Speeds:
- 6
- Airflow CFM:
- 7268
- Remote Included:
- Yes
- Wall Control Included:
- No
- Downrod Length:
- 4.5"
