Delta Breez Radiance RAD80L - 80 CFM Fan/Light with Heater

Delta Breez Radiance RAD80L - 80 CFM Fan/Light with Heater

(No reviews yet) Write a Review

Model: RAD80L
From the BreezRadiance Collection
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$165.09
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

The Delta BreezRadiance RAD80L combines a quiet bath fan, bathroom light and bathroom heater all in one with built-in thermostat and DC brushless motor for superior reliability and efficiency. Features a 1300 Watt heating element with built-in thermostat for consistent temperature. cUL listed and HVI certified.

Features

  • 80 CFM Single Speed Fan for spaces up to 80 sq. ft.
  • Brushless DC Motor outlasts typical AC motors by 2-1/2.
  • Quiet at 1.5 sones.
  • 1300W heating element evaluated by cUL for safety standards quickly and evenly distributes warmth.
  • Heater module equipped with thermal cutoff fuse and thermostat.
  • Separate 15 amp circuit required.
  • Housing size 14-3/8" x 8-1/4" x 5-1/2".
  • 4" duct.
  • UL and cUL listed for ceiling mount installation.
  • 3 yr. limited warranty.

Product Specs

Subcategory:
BreezRadiance
Static Pressure:
0.1 - 0.25
Maximum CFM:
80
Sones:
1.5
Heating Element (Watts):
1300
Duct Size:
4"
Duct Diameter:
4"
Energy Star:
Yes
Warranty:
3 Year Limited
Product Group:
Washroom/Bath
Product Subgroup:
Ventilation Fans
Collection:
BreezRadiance
Product Voltage:
120/60
Product Height:
5-1/2"
Product Category:
Ventilation Fans
Product Width:
16-13/16"
Department:
Plumbing
Product Wattage:
10.5 - 8.2
Product Depth:
10-11/16"

Delta Breez RAD80L – Frequently Asked Questions

1) What size bathroom is an 80 CFM fan like the Delta Breez RAD80L good for?
The RAD80L is a single speed 80 CFM unit sized for bathrooms up to about 80 square feet. A typical apartment or hotel three quarter bath falls well inside that. For larger master baths, or a room with a separate enclosed water closet or steam shower, you want more airflow or a second unit.
2) Does the Delta Breez RAD80L heater need its own circuit?
It does. The 1300 watt heating element means the unit has to run on a separate 15 amp circuit at 120V, 60Hz. That is the detail that most often turns this into an electrician call on a retrofit: if you are replacing a plain fan or a fan/light that shares a lighting circuit, you are pulling a new home run before this goes in.
3) How loud is the Delta Breez Radiance RAD80L bath fan?
Rated at 1.5 sones, which is quiet enough for a hotel guest bath or a bedroom-adjacent bath where a noisy fan generates complaints. Property managers replacing old builder-grade fans in occupied units usually feel this difference more than any other spec on the unit.
4) Does the Delta Breez RAD80L have a thermostat, or does the heater just run until you shut it off?
There is a built-in thermostat in the heater module, so the element cycles to hold temperature rather than running flat out the whole time the switch is on. The module also carries a thermal cutoff fuse as a second layer of protection.
5) Is the Delta Breez RAD80L Energy Star rated for a green building or utility rebate program?
Yes, the RAD80L carries an Energy Star rating, and it is HVI certified with airflow rated at 0.1 and 0.25 inches of static pressure. Those are the two figures a rebate program or a ventilation code compliance form typically asks for.
6) Why choose a DC brushless bath fan over a standard AC motor fan for rental units?
Motor life is the whole argument. The brushless DC motor in the Radiance RAD80L is stated to outlast a typical AC motor by 2-1/2 times, and the fan draws 10.5 to 8.2 watts across its rated static pressure points. On a portfolio where a failed fan means a service call and a unit entry, the longer motor life is usually what pays for the unit.
7) Is one fan/light/heater combo unit better than separate fixtures in a small bathroom?
In a bath with limited ceiling space, a combo like the BreezRadiance RAD80L puts exhaust, light and a 1300W heater in one 4 inch ducted housing and one ceiling cut. The trade-off is the dedicated 15 amp circuit the heater demands, plus multi-gang switching to run the three functions independently. If the bath already has adequate lighting and you only need air changes, a plain 80 CFM exhaust fan installs on far less electrical work.
