Schlage L9050 - Entrance/Office 07 Lever Mortise Lock - Grade 1 Non-Deadbolt Function Single Cylinder Keyed Lever Lock, Indicator with Text, Interior Indicator "Locked/Unlocked"

Schlage L9050 - Entrance/Office 07 Lever Mortise Lock - Grade 1 Non-Deadbolt Function Single Cylinder Keyed Lever Lock, Indicator with Text, Interior Indicator "Locked/Unlocked"

(No reviews yet) Write a Review

Model: L9050P 07B 626 IS-LOC
From the L9000 Series Collection
$1,624.00
$1,136.80
Selected Finish is
Selected Rose/Escutcheon is
Selected Cylinder is
Selected Keying is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,624.00
$1,136.80
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Default Attributes
Style: Same lever, rose and finish for both sides of the door with coordinating latch and strike.
Latch: ANSI/BHMA Certified A156.13-2012, Series 1000, Grade 1 Operational,
Grade 1 Security, UL Listed for 3-hour fire door (except L9076 and L9077).
With FSIC Interchangeable Core Cylinders: Grade 1 Operational, Grade 2 Security.
With SFIC Interchangeable Core Cylinders: Grade 1 Operational, Grade 3 Security.
Case Size: 4-7/16" x 6-1/16" x 1";
Armor Front: 1-1/4" x 8";
Strike: 1-1/4" x 4-7/8" Square corner, 1-3/16" lip, box;
Backset: 2-3/4";
Door Thickness: 1-3/4".


L9050 - ENTRANCE/OFFICE NON-DEADBOLD FUNCTION LOCK

  • Latchbolt retracted by lever/knob from either side unless outside lever is locked by key or thumbturn;
  • With outside locked, latchbolt retracted by key or inside lever;
  • Outside lever locked until unlocked by thumbturn or key;
  • Auxiliary latch deadlocks latchbolt when door is closed;
  • Inside lever always free for immediate egress.


Schlage L SERIES OVERVIEW

The Schlage L Series has long been the benchmark for mortise locks. The L Series is more than strength and security – it offers tremendous flexibility to allow it to meet the needs of most every application. Over 55 functions, 35 lever and knob designs, eight different roses and escutcheons, and a multitude of prep options are just the beginning.

180 degree visibility indicators, advanced motor-driven electrified functions, a universal lock case that supports 10 different functions, and the ability to suite across tubular, exit device, and multipoint locks allow the Schlage L Series to integrate seamlessly into any environment.


FEATURES & BENEFITS

Security

  • Exceeds ANSI/BHMA Grade 1 Security and Operational standards
  • Deadbolt functions include anti-saw pin in bolt to prevent cut-through
  • Security blocking hub prevents lock picking by removing levers

Function availability and compatibility

  • 55+ standard functions (custom functions are also available)
  • Universal lock case allows 10 functions to be created from a single lock body
  • Electrified locks auto detect 12V/24V DC, have customer-selectable EL/EU, and offer advanced features like: RX, DPS, latchbolt monitor and deadbolt monitor for application flexibility while offering leading energy efficiency

Aesthetics

  • 14 finishes
  • 33 lever, two knob, five rose and three escutcheon designs
  • Locking lever bushing eliminates exposed screws on inside levers
  • All levers suite with Von Duprin exit devices, along with related L Series products LE, LM9200, LM9300 and LT

Options

  • Exclusive 180° visibility indicator
  • Vandlgard® free-wheeling outside trim option is available on most functions, including electrified
  • Expansive options portfolio, including different door thickness, finish/trim combinations, tactile warning, anti-microbial coatings, etc.
  • New Gold Standard ligature resistant trim for behavioral health applications


AVAILABLE L SERIES FUNCTIONS

View the Schlage L Series catalog for descriptions of all available functions.


CERTIFICATIONS & TESTING

View the Schlage L Series catalog to see all specifications and certifications.

Certifications

  • Meets BAA (Buy American Act)
  • L9000: tested and certified under ANSI/BHMA A156.13, Grade 1 Security and Operational
  • UL listed for 3-hour fire door (except L9076 and L9077)
  • With interchangeable core cylinders: Grade 2 security
  • With concealed shell cylinder: A156.13 Grade 1 operational and security
  • ANSI/ASTM F476-76 Grade 40, UL listed
  • L400: tested and certified under ANSI/BHMA A156.36 Grade 1
  • California Referenced Standards Code: all levers with a return to door of 1/2" (64 mm) or less comply
  • UL/cUL listed for A label single doors, 4' x 10' and pairs 8' x 10'; letter F and UL symbol on latch front indicate listing
  • Electrified functions are UL19X listed for single-point locking applications
  • UL437 listed locking cylinder optional: specify Primus 20-500 Series cylinder
  • Miami-Dade NOA's and Florida Building Commission Listings
  • Meet ADA requirements

DOWNLOADS & RESOURCES



Technical resources


Manufacturer Resources

Product Specs

Subcategory:
Mortise Locks
Product Group:
Mechanical Locks
Series:
L Series
Function Description:
Latchbolt retracted by knob/lever from either side unless outside is made inoperative by key outside or by turning inside thumbturn. When outside is locked, latchbolt is retracted by key outside or by knob/lever inside.
Grade:
Grade 1
Duty Level:
Heavy Duty
Keyed Function:
Single Cylinder
Standard Cylinder:
Conventional 6-pin Cylinder, C Keyway
Handle Type:
Lever
Standard Strike:
10-072 1-1/4" x 4-7/8" Square Corner Strike, Box (1-3/16" Lip Length)
Mortise Case Size:
4-7/16" x 6-1/16" x 1"
Warranty:
3 Year Limited
Keyed:
Yes
ANSI/BHMA:
F04
Product Subgroup:
Mortise Locks and Trim
Product Type:
Indicator Lock
Commercial/Residential:
Commercial
Lock Type:
Mortise
Lock Function:
Entrance/Office
Product Attribute:
Indicator Locks
Handle Design:
07 Lever
Lever/Knob Design:
07 Lever
IMAP Policy:
Yes
Electronic:
No
Product Model:
L9050
Collection:
L9000 Series
Product Function:
Entrance/Office
Door Hand Direction:
Handed
Door Thickness Range:
1-3/4"
Product Substrate:
CRS with Zinc Dichromate Plating
Product Category:
Mechanical Locks
Backset (Distance):
2-3/4"
Department:
Door Hardware

Schlage L9050P 07B 626 IS-LOC – Frequently Asked Questions

1) Will the Schlage L9050 mortise lock fit a 1-3/4 inch door with a 2-3/4 inch backset prep?
That is exactly the prep it is built for. The L9050 is a 2-3/4 inch backset mortise lock for 1-3/4 inch doors. The lock case measures 4-7/16 x 6-1/16 x 1 inches and the armor front is 1-1/4 x 8 inches, so it drops into a standard ANSI mortise pocket. If your doors are thicker or thinner, the rose/escutcheon choice matters: the L cast/forged escutcheon covers 1-3/8 to 2-1/2 inch doors and the N wrought escutcheon covers 1-3/4 to 2-1/4 inch doors.
2) What does the Entrance/Office function on the Schlage L9050 actually do day to day?
Either lever retracts the latch normally. Turn the inside thumbturn or use the key outside and the outside lever locks; from then on the door opens with a key outside or the inside lever. The outside lever stays locked until the thumbturn or key releases it. An auxiliary latch deadlocks the latchbolt once the door closes, and the inside lever is always free for egress, so an office can be secured from inside without anyone being trapped.
3) Can staff tell from inside the room whether the Schlage L9050 is locked?
Yes. This version carries the interior 180 degree visibility indicator reading Locked or Unlocked in text, so someone standing inside the office or classroom can confirm the outside lever is secured without opening the door. That is the whole point of specifying the indicator variant over a plain L9050.
4) Is the Schlage L9050 handed, and what do I need to know before ordering?
It is a handed lock, so you need to determine the door's hand (and whether it is reverse bevel) before placing the order. Get that wrong and the lever and indicator end up on the wrong faces.
5) Does the Schlage L9050 meet Grade 1 and can it go on a fire-rated door?
The L9050 is ANSI/BHMA A156.13-2012 Series 1000, Grade 1 Operational and Grade 1 Security, and it is UL listed for 3-hour fire doors. Note the security grade changes with the cylinder: FSIC interchangeable core drops it to Grade 2 security, SFIC to Grade 3, while operational stays Grade 1. The ANSI function designation is F04.
6) Which cylinder option should I pick for the Schlage L9050 if my building is on an interchangeable core system?
There are seven cylinder choices. For small format IC, take B (SFIC less prep core) or H (7-pin SFIC prep with construction core). For Schlage full size IC, take J (FSIC less core), R (FSIC with core, S123 keyway) or T (FSIC with construction core). If you are keying conventionally, P supplies a 6-pin conventional cylinder in C keyway, which is the standard cylinder for this lock, and L ships it less conventional cylinder so your locksmith can fit your own. Keying is ordered separately as keyed different or keyed alike.
7) I need an occupancy indicator on a restroom door but not a keyed office lock. What should I use instead of the L9050?
The L9050 is an entrance/office function where the outside lever is locked by key or thumbturn and the inside lever is always free. For a restroom you generally want a privacy or occupancy function. The Accentra AUYPL02 is a Grade 1 privacy/bed/bath cylindrical lever lock with a visual status indicator. The Hager 3216 is a Grade 2 thumbturn x occupancy indicator deadbolt with a 1 inch throw for 1-3/4 inch doors and is fire rated. The Falcon H2171 is a Grade 2 public restroom interconnected lock with occupancy indicator and a single cylinder deadbolt.
8) What Grade 1 indicator lock can I use if the door is prepped for a cylindrical lock instead of a mortise pocket?
The Schlage L9050 with 07 lever is a mortise lock with a 4-7/16 inch x 6-1/16 inch x 1 inch case, so it needs a mortise pocket in the door edge. For a door already bored for a cylindrical lock, the Corbin Russwin CLX3320 NVSL is a Grade 1 lever lock with a visual status indicator, fire rated, covering 1-3/4 inch to 2 inch doors. Note the function differs: the CLX3320 NVSL is a privacy/bed/bath lock, while the L9050 is a keyed entrance/office function with a single cylinder.
9) What strike comes with the Schlage L9050, and will it work in my existing frame cutout?
It ships with the 10-072 strike, 1-1/4 x 4-7/8 inches, square corner, with a box and a 1-3/16 inch lip. That is the standard ANSI mortise strike footprint, so a frame already prepped for an ANSI mortise lock takes it directly. If your frame has a curved (radius) corner cutout or you need a longer lip to clear the stop, specify a different strike.
10) Can I match the Schlage L9050 to the exit devices and other locks already in my building?
Yes. L Series levers suite with Von Duprin exit devices and with the related L Series products LE, LM9200, LM9300 and LT, and the line will suite across tubular, exit device and multipoint locks. For a property manager standardizing openings, that means one lever design and finish can run from office doors to stairwell exits. Twelve finishes are offered here, from 605 bright brass through 626 satin chrome, 630 satin stainless and 622 matte black.
11) Should I use a mortise indicator lock like the L9050 or a separate indicator deadbolt?
An indicator deadbolt is a second, standalone piece of hardware you add above a passage set, and it locks nothing but itself. The L9050 puts latching, keyed outside control, thumbturn locking and the status indicator in one heavy duty mortise case, with the inside lever always free for egress. If the door is already prepped for a bored lock rather than a mortise pocket, a cylindrical or deadbolt option is the practical route: the Hager 3216 is a Grade 2 thumbturn by occupancy indicator deadbolt with a 1 inch throw for 1-3/4 inch doors, and the Accentra D292 is a Grade 2 cylindrical indicator deadbolt for 1-3/8 to 1-3/4 inch doors.
12) Does the Schlage L9050 have a deadbolt?
No deadbolt. The L9050 is a non-deadbolt function: security comes from the latchbolt plus an auxiliary latch that deadlocks it when the door closes, with the outside lever locked by key or thumbturn. If the spec calls for a projecting deadbolt on the opening, this is the wrong L9000 function.
13) Is the Schlage L9050 ADA compliant and does it qualify under Buy American?
Yes on both. The L Series meets ADA requirements and meets the Buy American Act, and all levers with a return to door of 1/2 inch or less comply with the California Referenced Standards Code. For institutional and government procurement it also carries Miami-Dade NOAs and Florida Building Commission listings.
14) What is the difference between the A and B wrought roses and the L or N escutcheons on the L9050?
A and B are wrought roses, small round trim around the lever. L is a cast or forged escutcheon, a full plate, and it covers doors from 1-3/8 to 2-1/2 inches. N is a wrought escutcheon for 1-3/4 to 2-1/4 inch doors. Pick a rose if you want minimal trim, or an escutcheon if you are covering an old plate footprint or working outside standard 1-3/4 inch thickness.
15) Is there a higher security cylinder option for the Schlage L9050?
Yes, a UL437 listed locking cylinder is available by specifying a Primus 20-500 Series cylinder in place of the standard conventional 6-pin C keyway cylinder. Order the lock less cylinder if you are supplying your own restricted keyway.
16) Can I add an indicator to an existing door with a separate deadbolt instead of replacing the whole lock with an L9050?
Yes. The L9050 is a complete mortise lock body, trim and 07 lever assembly that replaces everything in the door edge. If the existing latch set stays, an indicator deadbolt adds status display on its own: the Cal-Royal IND90-G2 is a Grade 1 indicator deadbolt with an ADA thumbturn, the Accentra D292 is a Grade 2 cylindrical deadbolt with thumbturn and indicator for 1-3/8 inch to 1-3/4 inch doors, and the Cal-Royal IND84 is a Grade 3 thumbturn x indicator deadbolt. Keep in mind the L9050 is a non-deadbolt entrance/office function, so an indicator deadbolt is an addition rather than a like-for-like swap.
17) What is the difference between the Schlage L9050 and a Grade 2 indicator deadbolt like the Falcon D271 or Arrow E50 for a storage room?
The L9050 is a Grade 1 heavy duty keyed mortise lock, single cylinder, entrance/office function, with the outside lever locked by key or inside thumbturn and the inside lever always free for egress. The Falcon D271 is a Grade 2 medium duty deadbolt with occupancy indicator and thumbturn inside, one-sided function. The Arrow E50 is a Grade 2 non-keyed exit deadlock with a Vacant/Occupied indicator outside, for 1-3/8 inch to 1-3/4 inch doors. The Falcon and Arrow units are deadbolts only and are not keyed lever sets, so they do not control a latch or provide lever operation.
18) What is the Schlage L9050 lock case made of?
Cold rolled steel with zinc dichromate plating on the case. That is the corrosion-resistant plating Schlage uses on the L9000 case, and it is one reason the line is rated heavy duty for high-traffic commercial openings.
